Natural Convection Flow of Heat Generating/Absorbing Fluid near a Vertical Plate with Ramped Temperature ()
1. Introduction
Several aspects of unsteady laminar free or natural convection flow have been studied extensively over the past 40 years. The interest in such problems stems from their important applications, such as the early stages of melting and in transient heating of insulating air gap by heat input at the start-up of furnaces. Also, time dependent laminar natural convection is likely to find wider use as it could provide the flow mechanism in some types of solar heating and ventilating passive systems. In modern electronic equipment, the vertical circuit boards include heat generating elements, and this situation can be modelled by parallel heated plates with upward flow in the intervening space [1].
Heat generation/absorption plays significant role in various physical phenomena such as convection in earth’s mantle [2], application in the field of nuclear energy and fire combustion modeling [3].
Natural convection flow of heat generating/absorbing fluid was studied by [4-6], and [7]. Vajravelu [8] concluded that the heat source/ sink play an important role in delaying the velocity and the temperature to reach the steady state condition. Several interests have been built in the study of flow of heat generating/absorbing fluid because as the temperature differences are increased appreciably, the volumetric heat generation/absorbing term may exert strong influence on the heat transfer and transitively on the flow [9]. Jha [9] discusses and analyze the flow behaviour of transient free convective flow of viscous incompressible fluid in a vertical channel due to asymmetric heating of the channel walls in the presence of temperature dependent heat sink. He concluded that an increase in heat sink parameter (S) decreases both skin friction (τ) and Nusselt number (Nu).
Unsteady flow formation in vertical channel due to symmetric and asymmetric heating has been studied by Jha et al. [10], and Singh et al. [11]. Paul et al. [12] presented analytical solutions for transient natural convection flow in a vertical channel by considering isofluxisothermal and isoflux-adiabetic boundary conditions respectively.
Chandran et al. [13] studied natural convection near a vertical plate with ramped temperature and obtained two different solutions, one valid for the fluid of Prandtl numbers different from unity and the other for which the Prandtl number is unity. They obtained analytical solutions under the assumption that the velocity and temperature conditions on the wall are continuous and welldefined. They concluded that the solutions for the nondimensional velocity and temperature variables depend upon the Prandtl number of the fluid, and the expression of the fluid velocity is not uniformly valid for all values of Pr. In their work, heat source or sink is absent. However, when the temperature differences are appreciably large, the volumetric heat generation (absorption) term may exert strong influence on the heat transfer and as a consequence, on the fluid flow as well.
The present work considers natural convection flow of heat generation/absorption fluid near a vertical plate with ramped temperature. The organization of the paper is as follows: The problem is formulated in Section 2. Two cases are considered under this section. First case discusses plate with continuous ramped temperature and second case considers plate with isothermal temperature. Results and discussion is presented in Section 3. Section 4 contains the concluding remarks
2. Mathematical Formulations
The flow considers unsteady natural convective flow of a viscous incompressible fluid of arbitrary Prandtl number near a vertical plate. Figure 1 shows the physical configuration. An arbitrary Origin O on the wall is chosen, the axis Ox' is taken along the wall in the upward direction and Oy' axis is taken perpendicular to it into the fluid. For time t' ≤ 0 both the fluid and the plate are at rest and at the constant temperature
. When the time is greater than zero i.e. t' > 0 the temperature of the plate is increased or decreased to
when t' ≤ t0 and thereafter, for t' > t0 is maintained at the constant temperature
. The objective here is to analyze the unsteady natural convective flow of heat generating/absorbing fluid with ramped temperature. The flow is assumed to be laminar and therefore, the effects of the convective and pressure gradient terms in the momentum and energy equations are neglected. Here the physical variables become functions of the time variable t' and the space variable y' only as a result of the boundary layer approximations By the use of Boussinesq’s approximation, the governing equations for the flow problem in dimensional form are:
(1)
(2)
In the present analysis we have considered the heat generation (absorption) of the type Vajravelu and Sastri, [7]; Foraboschi and Federico, [3]
(3)
The initial and boundary conditions to be satisfied are:
(4)
Solutions of (1) and (2) can be obtained subject to the condition (4) in non-dimensional form and as such the non-dimensional quantities are introduced as follows
(5)
Using Equation (5) in (1) and (2), the momentum and energy equations are presented in dimensionless form as
(6)
According to the above non-dimensional process, the characteristic time
can be defined as
(7)
The initial and boundary conditions given by equations (4) now become
(8)
The solutions of Equations (6) and (7) under condition (9) were obtained using Laplace transform techniques
(9)
2.1. Case 1. Plate with Continuous Ramped Temperature
Using partial fraction with detailed simplifications and shifting on the t-axis, the solution can be written as
(10)
(11)
where
is the unit step function.
The Nusselt number (Nu) and Skin friction (τ) which are respectively measures of the heat transfer rate and shear stress at the boundary are expressed as follows
(12)
(13)
2.2. Case 2. Plate with Isothermal Temperature
Analytical expressions for the temperature and velocity variables are given in Equations (10) and (11) for fluid flows with heat generating/absorbing near a vertical plate with ramped temperature.
To show the effect of the ramped temperature distribution of the boundary on the flow, it may be interesting to compare such a flow with the one near a plate with isothermal temperature. Under the same assumptions considered in this article, the temperature and velocity field for the fluid flow with heat generating/absorbing near an isothermal, plate can be written as follows
(14)
(15)
The rate of heat transfer on the wall and the skin friction are given as follows
(16)
(17)
where
are defined in the appendix.
3. Results and Discussion
For the numerical validation of our results, we have chosen physically meaningful values of the parameters entering the problem. In Figures 2-12, the variations of the physical variables of interest have been plotted. Temperature profile for ramped and isothermal boundary conditions for different values of time is presented in Figure 2 while keeping the heat sink parameter S and the Prandtl number constant. It shows that as time t increases the temperature increases. In Figure 3 the temperature presents an inversely proportional relationship with Pr. Also the temperature decays with distance. For fluid with large Pr, the temperature decays faster with distance which makes thermal boundary layer to decrease. This is expected since fluid with large Pr has low thermal diffusivity and hence heat penetration is less when Pr is large. For fluid with low Pr the temperature increases and thereby increasing the thermal boundary layer. Figure 4 shows temperature profile for ramped and isothermal temperature boundary conditions. As the heat sink parameter (S) increases the temperature decreases for both ramped and isothermal case. It is seen from Figure 4 that the fluid temperature is greater in the case of isothermal plate than in the case of ramped temperature at the plate. This should be expected since in the latter case, the heating of the fluid takes place gradually than in the isothermal case.
Figure 5 shows variation of velocity due to ramped
Figure 2. Temperature Profile for ramped temperature and isothermal boundary conditions for different values of t (S = 0.2 and Pr = 0.71).
Figure 3. Temperature Profile for ramped temperature and isothermal boundary conditions for different values of Pr (S = 0.2 and t = 0.5).
Figure 4. Temperature profile for ramped temperature and isothermal boundary conditions for different values of S (Pr = 0.71 and t = 0.5).
Figure 5. Ramped velocity profile for different values of t (S = 0.2 and Pr = 0.71).
plate temperature for different values of time (t). As time increases the velocity increases. Figure 6 shows velocity profile for different values of the heat sink (S). From Figure 6, it is clear that velocity decreases with increase of heat sink parameter (S) for thermal boundary conditions (i.e. ramped as well as isothermal). Figures 7 and 8 show two profiles corresponding to ramped velocity and isothermal boundary conditions. In Figure 7 for 0 < t < 1, the velocity increases after which it starts descending. It was observed that the presence of heat sink S reduces the velocity profile for both ramped and isothermal cases. In Figure 8, it is observed that for very small values of time, the velocity profiles are nearly flat, but assume parabolic shapes near the plate as t increases. Moreover, the points of maxima on the curves get shifted to the right, as time increase. It is also seen that the velocity increases monotonically with the temporal variable t. The same observation is made, that the velocity on the ramped temperature plate is always less than that of the flow induced by a plate of isothermal temperature and this agrees with earlier observation made with regards to the temperature variation.
Figure 6. Ramped velocity profile for different values of S (t = 0.5 and Pr = 0.71).
Figure 7. Variation of velocity (
). Two profiles corresponding to ramped and isothermal boundary conditions for different values of S (t = 0.5 and Pr = 0.71).
Figure 8. Variation of velocity profile (
) corresponding to ramped and isothermal boundary conditions for different t (S= 0.2 and Pr = 0.71).
Figure 9. Variation of the Nusselt number (
) for different Pr corresponding to ramped and isothermal boundary conditions and
.
Figure 9 shows variation of the Nusselt number (Nu) corresponding to ramped and isothermal boundary conditions. For t < 1, the Nusselt number increase with time. There is a sharp decrease for isothermal case between 1 < t < 1.5 and 0 < t ≤ 0.5 for the ramped case. The Nusselt number increases as Pr increases because temperature reduces with increasing Pr thereby increasing the temperature gradient between the wall and the fluid and hence an increase in the rate of heat transfer is achieved. In Figure 10, as the Prandtl number increases the Nusselt number increases for both ramped and isothermal cases. It is observed that for 0 < S < 0.5 the Nusselt number is increasing and for 0.5 < S < 1 it is decreasing while it assumed constant value for S > 1 It is also seen that for
