Unidirectional Sound Signage for Speech Frequency Range Using Multiple-Loudspeaker Reproduction System


Human safety is the most important issue in disaster management. Speech is a sound signal containing information that is easily and quickly understood by humans. Using speech as sound signage in emergency systems can effectively increase human safety in low or poor visibility conditions such as in smoke-filled situations. However, reflections of sound through walls, floor surfaces, and ceilings will affect clarity of speech. Unfortunately, because of the characteristics of sound reproduction systems, a single loudspeaker propagates sound waves omni-directionally at low frequencies. This paper proposes a simple multiple-loudspeaker system for reproducing sound with uni-directional characteristics. The proposed system consists mainly of a primary loudspeaker for introducing sound in the desired beam, a secondary loudspeaker for reducing gain in the undesired direction, and digital filters. An adaptive finite-impulse-response (FIR) filter is used to produce the controlling sound by implementing a filtered-x least-mean-square algorithm, and a delay filter for adjusting the time alignment of sound propagation between primary and secondary sources at the control point. Several operational conditions for illustrating real situations and reflections were considered in an anechoic chamber. Experimental results show the directivity patterns of the proposed multiple-loudspeaker system for the required conditions. In a low frequency range, the system is able to control unidirectional propagation; there is a sound beam in the desired direction and, conversely, reduction of gain in the undesired direction around the control point.

Share and Cite:

V. Canisius Poekoel, K. Hira, Y. Chisaki and T. Usagawa, "Unidirectional Sound Signage for Speech Frequency Range Using Multiple-Loudspeaker Reproduction System," Open Journal of Acoustics, Vol. 3 No. 4, 2013, pp. 120-126. doi: 10.4236/oja.2013.34018.

Conflicts of Interest

The authors declare no conflicts of interest.


[1] L. C. Broer and S. J. Wijngaarden, “Directional Sound Evaluation from Smokefilled Tunnels,” Proceedings of First International Symposium Safe and Reliable Tunnels Innovative European Achievements, Prague, 2004, pp. 33-41.
[2] S. Yokohama, H. Tachibana, S. Sakamoto and S. Tazawa, “Subjective Experiment on Speech-rate of Emergency Evacuation Announcement in a Tunnel,” Proceedings of Euronoise, 30 May - 1 June 2006, Tampere.
[3] S. Yokohama, S. Sakamoto, H. Tachibana and S. Tazawa, “Study on the Application of Time-delay Technique to Public Address System in a Tunnel,” Proceedings of Inter-noise, Rio de Janeiro Brazil, 2005.
[4] I. Kakuhari, H. Hashimoto and K. Terai, “Development of a Loudspeaker System with a Unidirectional Radiation Pattern in a Speech Frequency Range,” Journal of Acoustic Society of Japan, Vol. 21, No. 6, 2002, pp. 369-373.
[5] T. Usagawa, S. Murakami, V. C. Poekoel and Y. Chisaki, “On a Unidirectional Loudspeaker System for Low Frequency Range Reproduction Using ANC Technique,” Proceedings of Inter-Noise, Osaka, 4-7 September 2011, pp. 1-5.
[6] V. C. Poekoel, Y. Chisaki and T. Usagawa, “Uni-Directional Characteristics Developing in Low Frequencies Using Two Loudspeakers with Adaptive FIR Filter,” Proceedings of Youngnam ASK-Kyushu ASJ Joint Conference on Acoustics, 26 January 2013, pp. 66-69.
[7] V. C. Poekoel, Y. Chisaki and T. Usagawa, “Directivity Control of Loudspeaker System in Low Frequency Range,” Proceedings of the 7th International Conference on Information and Communication Technology, ICTS, Bali Indonesia, 15-16 May 2013, pp. 257-261.
[8] V. C. Poekoel, K. Hira, Y. Chisaki and T. Usagawa, “Effectiveness of Multiple Loudspeaker System for Developing a Low Frequency Uni-Directional Sound Reproduction System,” Proceedings of the 66th Joint Conference of Electrical and Electronics Engineers in Kyushu, JCEEE, Kumamoto, 25-26 September 2013.
[9] Y. Suzuki, F. Asano, H. Y. Kim and T. Sone, “An Optimum Computer-Generated Pulse Signal Suitable for the Measurement of Very Long Impulse Responses,” Journal of Acoustic Society of America, Vol. 97, No. 2, 1995, pp. 1119-1123. http://dx.doi.org/10.1121/1.412224
