Physical Measurements for the Accuracy of Cone-Beam CT in Dental Radiography

Abstract Full-Text HTML Download Download as PDF (Size:572KB) PP. 57-64
DOI: 10.4236/ojmi.2014.42008    3,563 Downloads   5,137 Views   Citations

ABSTRACT

The introduction of cone-beam computed tomography (CBCT) for the maxillofacial imaging provided opportunities for dental practitioners to request multiplanar imaging. Currently CBCT is used during implant treatment-planning to measure accurately the height of bone available for implant placement to avoid serious problems e.g. compromising vital structure such as the inferior alveolar nerve during placement of implants. We present a physical method to assess the accuracy of measurements obtained from an i-CAT CBCT dental radiography unit used at king abdulaziz university hospital and to appraise the effect of voxel size on the accuracy of measurement by an i-CAT CBCT unit. Not significant difference was found between the physical and CBCT measurements for all the samples. The maximum measurements variation was + or -0.15 mm. Therefore, the linear measurements from i-CAT CBCT unit are accurate and the adjustment of the scan parameters like the FOV and voxel size will not significantly affect this accuracy.

Conflicts of Interest

The authors declare no conflicts of interest.

Cite this paper

Shaibah, W. , Yamany, I. and Jastaniah, S. (2014) Physical Measurements for the Accuracy of Cone-Beam CT in Dental Radiography. Open Journal of Medical Imaging, 4, 57-64. doi: 10.4236/ojmi.2014.42008.

References

[1] Zoller, J.E. and Neugebauer, J. (2008) Fundamental of Cone-Beam Volumetric Imaging Technology. In: Cone-Beam Volumetric Imaging in Dental, Oral and Maxillofacial Medicine: Fundamentals, Diagnostics, and Treatment Planning, Quintessence Publishing Company Limited, New Malden, 22-23.
[2] Sukovic, P. (2004) Cone Beam Computed Tomography in Dentomaxillofacial Imaging. American Association of Dental Maxillofacial Radiographic Technicians, from the Winter 2004 AADMRT Newsletter.
[3] Scarfe, W. and Farman, A. (2008) What Is Cone-Beam CT and How Does It Work? Dental Clinics of North America, 52, 707-730.
http://dx.doi.org/10.1016/j.cden.2008.05.005
[4] Scarfe, W., Farman, A. and Sukovic, P. (2006) Clinical Applications of Cone-Beam Computed Tomography in Dental Practice. Journal of the Canadian Dental Association, 72, 75-80.
[5] Scarfe, W. and Farman, A. (2007) Cone Beam Computed Tomography: A Paradigm Shift for Clinical Dentistry. Australasian Dental Practice, July/August, 108-104.
[6] Alshehri, M.A., Alamri, H.M. and Alshalhoob, M.A. (2012) CBCT Applications in Dental Practice. General Dentistry, 60, 390-400; quiz 401-402.
[7] Ibraheem, I. (2012) Reduction of Artifacts in Dental Cone Beam CT Images to Improve the Three Dimensional Image Reconstruction. Journal of Biomedical Science and Engineering, 5, 409-415.
http://www.scirp.org/journal/jbise/ http://dx.doi.org/10.4236/jbise.2012.58052
[8] Jaju, P.P., Jain, M., Singh, A. and Gupta, A. (2013) Artefacts in Cone Beam CT. Open Journal of Stomatology, 3, 292-297.
http://www.scirp.org/journal/ojst/ http://dx.doi.org/10.4236/ojst.2013.35049
[9] Levato, C., Farman, A., Chenin, D. and Scarfe, W. (2009) Cone-Beam Computed Tomography: A Clinician’s Perspective. Inside Dentistry, 5, 66-73.
[10] Ganguly, R. (2009) Accuracy of Linear Measurement in Galileos Cone-Beam CT under Simulated Clinical Condition. Master’s Thesis, University of Iowa, Iowa City.
[11] Mills, E.J. (2013) CBCT and Implants: Improving Patient Care, One Implant at a Time, Part I. The Dentistry iQ Network.
http://www.dentaleconomics.com/articles/print/volume-101/issue-4/features/cbct-and-implants-improving-patient-care-one-implant-at-a-time-part-1.html
[12] Roth, J.S. (2011) CBCT Technology: Endodontics and Beyond, Part 2. Dentistry Today, Monday, 7 March 2011.
http://www.dentistrytoday.com/endodontics/4731-cbct-technology-endodontics-and-beyond-part-2
[13] Nelson, S.J. (2009) Introduction to Dental Anatomy. In: Wheeler’s Dental Anatomy, Physiology, and Occlusion, 9th Edition, Saunders Elsevier, St. Louis, 18-29.
[14] Phinney, D.J. and Halstead, J.H. (2004) Embryology and Histology. In: Delmar’s Dental Assisting: A Comprehensive Approach, 2nd Edition, Cengage Learning, Boston, 89-100.
[15] http://www.dentistry.unc.edu/NRA/PanAnatomy/skull_images/mandibular-canal-s.html
[16] Vartiainen, V., Siponen, M., Roseberg, J. and Apaja-Sarkkinen, M. (2008) Widening of the Inferior Alveolar Canal: A Case Report with Atypical Lymphocytic Infiltration of the Nerve. Oral Surgery, Oral Medicine, Oral Pathology, Oral Radiology, and Endodontology, 106, e35-e39.
[17] McCabe, J.F. and Walls, A.W.G. (2008) Endodontic Materials. In: Applied Dental Materials, 9th Edition, Wiley- Blackwell, Hoboken, 289-294.
[18] I-CAT CBCT Measurements.
http://en.wikipedia.org/wiki/Vernier_caliper#Vernier_caliper
[19] http://www.sedentexct.eu/content/guidelines-cbct-dental-and-maxillofacial-radiology
