Preliminary study of binary protein adsorption system and potential bioseparation under homogeneous field of shear in airlift biocontactor


This paper investigates the bioseparation of binary protein mixtures using polystyrene based anion exchange resin. Adsorption experiments were conducted in batch mode using draft-tube internally recirculate dair lift biocontactor in comparison with the conventional shake flask batch adsorption equilibrium experiments. Binary protein mixtures contained bovine serum albumin (BSA) and bovine haemoglobin (BHb) at different initial fractions. Results from single solute adsorption experiments in biocontactor showed that both proteins were equally adsorbed onto the resin with equilibrium reached in an equal time period. This represents similar affinities towards the negatively charged resin surface, although BSA was expected to adsorb through specific forces. Adsorption results showed that BSA has hindered the BHb adsorption in the biocontactor, although adsorption of both proteins was equally hindered in the shake flasks adsorption experiments. Moreover, adsorption of BHb was inhibited up to 29% in the presence of BSA compared to the adsorption of BHb from a solution containing single solute of BHb at the same initial concentration. Similarly, the presence of BHb has hindered the adsorption of BSA by 59%. Adsorptions of both BSA and BHb from binary solution when each formed 75% initial fraction while the other protein formed the remaining 25% were relatively low with equilibrium reached in shorter time. Moreover, considerable amount of proteins remained in the solution, which demonstrates that multilayer adsorption most likely didn’t occur at the relatively small protein concentrations used in the present study. In general, the higher adsorption of BHb can also be related to the compressibility of its molecules which allowed for higher adsorption capacity. The homogeneous and lower shear environment in the airlift biocontactor compared to the other conventional batch adsorption in shake flask reduced the compressibility of BHb that caused higher BSA adsorption from binary solutions of BSA and BHb, which allowed for better bioseparation of both proteins.

Share and Cite:

Dahman, Y. and Jayasuriya, K. (2013) Preliminary study of binary protein adsorption system and potential bioseparation under homogeneous field of shear in airlift biocontactor. Advances in Bioscience and Biotechnology, 4, 710-718. doi: 10.4236/abb.2013.46094.

Conflicts of Interest

The authors declare no conflicts of interest.


[1] Bickerstaff, G.F. (1997) Immobilization of enzymes and cells. Human Press, Totowa.
[2] Rapoza, R. and Horbett, T. (1990) The effects of concentration and adsorption time on the elutability of adsorbed proteins in surfactant solutions of varying structures and concentrations. Journal of Colloid and Interface Science, 136, 480-492. doi:10.1016/0021-9797(90)90395-5
[3] Van Holde, K.E., Johnson, W.C. and Ho, P.S. (1998) Principles of physical biochemistry. Prentice-Hall Inc., New Jersey.
[4] Denizli, A. and Piskin, E. (2001) Dye-legend affinity systems. Journal of Biochemical and Biophysical Methods, 49, 391-416. doi:10.1016/S0165-022X(01)00209-3
[5] Dahman, Y., Puskas, J., Margaritis, A. and Cunningham, M. (2004) Novel thymine-functionalized polystyrenes for applications in biotechnology. 2. Adsorption of Model Proteins. Biomacromolecules, 5, 1412-1421. doi:10.1021/bm034497r
[6] Kondo, A. and Higashitani, K. (1992) Adsorption of model proteins with wide variation in molecular properties on colloid particles. Journal of Colloid and Interface Science, 150, 344-351. doi:10.1016/0021-9797(92)90204-Y
[7] Shirahama, H., Susuki, K. and Suzawa, Y. (1989) Bovine haemoglobin adsorption onto polymer lattices. Journal of Colloid and Interface Science, 129, 483-490. doi:10.1016/0021-9797(89)90462-1
[8] Absolom, D., Zingg, W. and Neumann, A. (1997) Protein adsorption to polymer particles: Role of surface properties. Journal of Biomedical Materials Research, 21, 161171. doi:10.1002/jbm.820210202
[9] Yoon, J.Y., Park, H.Y., Kim, J.H. and Kim, W.S. (1998) Interpretation of protein adsorption phenomena onto functional microspheres. Journal of Colloids and Surface B, 12, 15-26. doi:10.1016/S0927-7765(98)00045-9
[10] Ghadge, R.S., Patwardhan, A.W., Sawant, S.B. and Joshi, J.B. (2005) Effect of flow pattern on cellulase deactivation in stirred tank bioreactors. Chemical Engineering Science, 60, 1067-1083. doi:10.1016/j.ces.2004.09.069
[11] Rathore, N. and Rajan, R.S. (2008) Current perspectives on stability of protein drug products during formulation, fill and finish operations. Biotechnology Progress, 24, 504514. doi:10.1021/bp070462h
[12] Jaspe, J. and Hagen, S.J. (2006) Do protein molecules unfold in a simple shear flow? Biophysical Journal, 91, 3415-3424. doi:10.1529/biophysj.106.089367
[13] Otero, C., Fernandez-Perez, M. and Perez-Gil, J. (2005) Effects of interactions with micellar interfaces on the activity and structure of different lipolytic isoenzymes from Candida rugosa. Enzyme and Microbial Technology, 37, 695-703. doi:10.1016/j.enzmictec.2005.03.023
[14] Wierenga, P.A., Egmond, M.R., Voragen, A. and de Jongh, H. (2006) The adsorption and unfolding kinetics determines the folding state of proteins at the air-water interface and thereby the equation of state. Journal of Colloid and Interface Science, 299, 850-857. doi:10.1016/j.jcis.2006.03.016
[15] Postel, C., Abillon, O. and Desbat, B. (2003) Structure and denaturation of adsorbed lysozyme at the air-water interface. Journal of Colloid and Interface Science, 266, 7481. doi:10.1016/S0021-9797(03)00571-X
[16] Garcia, M., Bonen, J., Ramirez-Vick, M. and Sadaka, A.V. (1999) Bioseparation process science. Blackwell, California.
[17] Ahuja, S. (2000) Handbook of bioseparations. Academic, California.
[18] Moo-Young, M. and Chisti, Y. (1989) On the calculation of shear rate and apparent viscosity in airlift and bubble column bioreactors. Biotechnology and Bioengineering, 34, 1391-1392. doi:10.1002/bit.260341107
[19] Chisti, Y. (1989) Airlift bioreactors. Elsevier, New York.
[20] Chisti, Y., Wenge, F. and Moo-Young, M. (1995) Relationship between riser and downcomer gas hold-up in internal-loop airlift reactors without gas-liquid separators. Chemical Engineering Journal, 57, 7-13.
[21] Peterson, E. and Margaritis, A. (2001) Hydrodynamic and mass transfer characteristics of three-phase gas-lift bioreactor systems. Critical Reviews in Biotechnology, 21, 233-294. doi:10.1080/07388550108984172
[22] Revilla, J., El-Aissari, A., Carriere, P. and Pichot, C. (1996) Adsorption of bovine serum albumin onto polystyrene latex particles bearing saccharidic moieties. Journal of Colloid and Interface Science, 180, 405-412. doi:10.1006/jcis.1996.0319
[23] Causserand, C., Kara, Y. and Aimar, P.J. (2001) Protein fractionation using selective adsorption on clay surface before filtration. Journal of Membrane Science, 186, 165181. doi:10.1016/S0376-7388(01)00332-5
[24] Dickinson, E. (1999) Adsorbed protein layers at fluid interfaces: Interactions, structure and surface rheology. Journal of Colloids and Interfaces B: Biointerfaces, 15, 161-176.
[25] McMurry, J. (1999) Organic chemistry. 5th Edition, Brooks Cole, California.
