ABSTRACT

Coronary artery disease (CAD) is a leading cause of mortality and morbidity in developed countries, although percutaneous coronary intervention and coronary artery bypass grafting have developed recently. Appropriate diagnosis will improve the prevention, treatment, and care of all patients. We could diagnose only calcification in the coronary arteries with the past computed tomography. Recently, multislice computed tomography has been already accepted as an efficient non-invasive tool for the detection of coronary artery stenosis. We get to estimate the coronary artery stenosis with cardiac computed tomography. We discuss the usefulness of cardiac computed tomography for the risk stratification of coronary artery atherosclerosis.

1. Introduction

Coronary artery disease (CAD) is a leading cause of mortality and morbidity in developed countries [1]. CAD is a common and sometimes disabling disorder, although percutaneous coronary intervention and coronary artery bypass grafting have developed. Medical doctors need to prevent acute coronary syndrome in the stage of no significant stenotic coronary artery atherosclerosis. The development of non-invasive cardiac imaging tools (particularly, cardiac computed tomography, echocardiography and so on) for the diagnostic and prognostic assessments of patients is evolving evidence base for various treatment strategies. Cardiac catheterization is golden standard for the diagnosis of CAD. Although the risk of adverse events for invasive coronary angiography is generally considered to be low, potential life-threatening complications can arise, including not only coronary artery dissection, but also arrhythmia, stroke, hemorrhage, myocardial infarction (MI), and death [2]. Computed tomography (CT) imaging was introduced in 1972 [3]. The ability to obtain cross-sectional images of the computer-assisted tomography, Sir Geoffrey N. Hounsfield and Allan M. Cormack were awarded the Nobel prize in Medicine in 1979. Moreover, cardiac CT has been developing.

Although coronary CT angiography presently cannot be considered a routine replacement for invasive coronary angiography, because the diagnostic accuracy of coronary CT angiography is not greater than that of invasive coronary angiography, cardiac CT is useful for diagnosis of coronary artery disease non-invasively.

We discuss the usefulness of cardiac computed tomography for the risk stratification of coronary artery atherosclerosis.

2. The Diagnosis of Coronary Artery Disease with Cardiac CT

Table 1 shows that the likelihood of ischemia due to CAD. We estimate the likelihood of ischemia in the medical history, physical examination, and cardiac biomarker measurements in patients with symptoms suggestive of acute coronary syndrome. Invasive coronary angiography is more appropriate than CT angiography for patients with a high pretest likelihood of CAD. CT angiography is appropriate for stable patients with acute chest pain [4]. A recent guideline reports several appropriate indications for coronary CT angiography. Firstly, they are symptomatic patients with intermediate likelihood of CAD but in whom stress testing, including in electrocardiogram, echocardiogram, and scintigram is not possible or the result of stress testing is equivocal or uninterpretable with acute chest pain. Secondly, they are

Table 1. We show the likelihood that signs and symptoms represent acute coronary syndrome secondary to CAD. CAD indicates coronary artery disease; CK-MB: MB fraction of creatine kinase; ECG: electrocardiogram, MI: myocardial infarction, MR: mitral regurgitation. TnI: troponin I, TnT: troponin T (6).

patients with acute chest pain and intermediate likelihood of CAD but absence of ECG changes and normal myocardial enzyme levels (Figures 1 and 2) [5,6].

We often careful for some disadvantages of cardiac CT. Firstly, we should be careful for the renal function, because contrast nephropathy sometimes develops. And, we should be careful not to use cardiac CT for less than 50 years old women, because of radiation exposure. Next, we should confirm the patient’s contrast allergy. Then, we should be careful for the calcified coronary arteries in hemodialysis and elderly patients with plain CT, because it is difficult to diagnose CAD in the patients with many calcified coronary arteries. Lastly, we control the patient’s heart rate in less than 60 beats per minute with beta blocker, especially for arrhythmia patients.

The best approaches to the care of CAD, improving not only the efficacy and safety of treatments, but also the cost.

The stratification of pretest probability of CAD are shown in Table 1.

The age, sex, and symptom groups were then used to classify each patient before diagnostic testing into 1 of 32 subsets associated with a specific likelihood for significant angiographic coronary artery disease. These preset likelihoods which are based upon a previously published review of 28948 patients in the medical literature [7,8] are listed in Table 2.

Very low pretest probability is less than 5% pretest probability of CAD.

Low pretest probability is between 5% and 10% pretest probability of CAD.

Intermediate pretest probability is between 10% and 90% pretest probability of CAD. High pretest probability is more than 90% preset probability of CAD.

The Duke’s treadmill score (Bruce protocol) is calculated as follows: duration of exercise in minutes (5 × the maximal ST segment deviation during or after exercise, in millimeters) − (4 × the treadmill angina index).

The angina index has a value of 0: if the patient had nonlimiting angina, 1: if exercise angina occurred, and 2: if angina was the reason the patient stopped exercising. The score had a range from −25 (highest risk) to +15 (lowest risk).

The outpatients had treadmill scores indicating low risk (≥+5) and their four-year survival rate was 99% (average annual mortality rate, 0.25%). The outpatients had scores indicating high risk (<−10) and their four-year survival rate was 79% (average annual mortality rate, 5.0%) [9].

Suspected CAD patients with chest symptom or abnormal result of electrocardiogram and echocardiogram should be performed exercise stress electrocardiogram for the diagnosis of ischemia if possible. CAG is performed in the high risk patients or patients diagnosed ischemia. Stress scintigram and/or cardiac CT are added in the moderate risk patients. As far as stress test, the patients who are unable to exercise sufficiently are selected drug stress test, although exercise stress test is

Table 2. Pretest probability of CAD by age, sex, and symptom.

more physiologic (Figures 3 and 4).

1) Hospital condition for cardiac CT a) The staffs have sufficient experience on cardiac CT.

b) The hospital equips with cardiac CT which is better than 64 slice.

c) The staffs are able to show good images and work the proper reporting system.

d) The staffs understood the feature of each CAG and cardiac CT.

e) The staffs try to make the protocol for lowering the radiation exposure.

2) Patient condition for cardiac CT a) The staffs are careful of the risk of radiation exposure in women which is less than 50 years old.

b) It is difficult to diagnose in the patients with many calcified coronary arteries, for example, the patients with hemodialysis, and the elderly patients.

c) Serum creatinin is less than 2.0 mg/dL.

d) The eGFR is more than 60 mL/min/1.73m².

e) Diabetes mellitus nephropathy patients, including to microalbuminuria are not recommended.

f) The contrast alergy patients are not recommended.

g) Asthma patients are not recommended.

3) Stress SPECT a) The stress test is recommended exercise stress, rather than drug stress.

b) The diagnosis is recommended 17 or 20 segment method to diagnose the area and degree of ischemia.

c) The staff confirms whether the patients have contraindication of the stress drug.

d) Echocardiogram and perfusion MRI can be alternative stress test depending on the facilities.

e) Less than 50% count of maximum count in the defect area is more than moderate ischemia.

f) The count between 50% and 70% count of maximum count in the defect area is mild ischemia.

g) More than 70% count of maximum count is normal myocardium.

3. The Visualization of the Coronary Artery Lumen in Cardiac CT

Cardiac CT can be applied for visualization of the coronary artery lumen after intravenous injection of a contrast agent. The administration of beta blockers before the cardiac CT scan and the use of sublingual nitroglycerin can achieve coronary vasodilation and maximize image quality. Studies using 64 slice CT scanning with invasive coronary angiography report sensitivities and specificities of 94% - 99% and 86% - 97%, respectively, and importantly, a negative predictive value of 98% - 100% [10-12]. Patency and occlusion of bypass grafts can be established with very high accuracy in cardiac CT [13, 14]. But, the limitations are the detection of stenoses at

the site of anastomosis to the coronary artery and in the peripheral run-off coronary artery. Cardiac CT with volume rendering images is useful to patients with known or suspected congenital coronary artery anomalies. Cardiac CT can classify the origin and the complex course of anomalous coronary arteries [15,16].

Although artifacts caused by metal and partial volume effects limit the evaluation of in-stent restenosis with 64-slice CT, the sensitivity was 91%, specificity was 91%, positive predictive value was 68%, and negative predictive value was 98% [9].

It is important to note that an analysis of the degree of coronary stenosis and risk areas of the myocardium can be performed without additional radiation exposure or contrast injections. The introduction of myocardial assessment by first-pass scan protocols into clinical practice is easy without additional stress and cost.

4. The Morphology of Atherosclerosis in the Coronary Artery

Atherosclerosis consists of two pathological processes. Atherosis characterized by morphologic atheromatous lesions appearing in the intima, and sclerosis characterized by an increase in stiffness of the vessel walls.

Cardiac CT has several potential applications for patients with coronary artery disease. Cardiac CT can demonstrate the morphological consequences of coronary artery disease and estimate ventricular function, perfusion. Recently, the visualization of coronary artery has been developing with coronary artery calcification, coronary artery stenosis.

Non-enhanced CT studies of the heart are almost exclusively performed to assess calcified structures within the heart and coronary artery calcification (CAC).

As far as the pathology of coronary artery, CAC is a surrogate marker for coronary atherosclerotic plaque. In the coronary arteries, calcifications occur almost exclusively in the context of atherosclerotic changes [17,18]. In the most patients with acute coronary syndromes, CAC can be detected, and the amount of calcium in these patients is substantially greater than in the patients without coronary artery disease [19]. With the exception of patients in the renal failure, nonatherosclerotic calcification of the coronary artery wall is rare. CAC is not associated with stability or instability of an individual plaque [18]. Plaques with healed ruptures contain calcium, whereas plaque erosions are frequently not calcified.

Calcification does not occur in a normal vessel wall, it therefore indicates the presence of atherosclerosis, and endothelial dysfunction in the coronary arteries but is not specific for luminal obstruction.

However, the absence of detectable CAC rules out the presence of significant coronary artery stenoses with high negative predictive value [17]. Because even coronary atherosclerotic plaque burden is not necessarily associated with hemodynamically luminal narrowing, even the detection of large amounts of calcium does not imply the presence of the significant stenoses. The greatest potential for CAC detection could be as a marker for CAD prognosis in asymptomatic patients. The presence and severity of CAC has independent and incremental value in the estimation of death or nonfatal MI [20]. Coronary calcium is important in the risk stratification, and noncalcified atherosclerosis is also important. Some studies against intravascular ultrasound have reported sensitivities of 53 to 83 percent for the detection of noncalcified plaque by 16 and 64 slice CT [21-23]. Noncalcified plaque is consisted of lipid-rich plaques and fibrous plaques. Lipid-rich plaque (14 to 72 HU) is lower CT Hounsfield attenuation numbers than fibrous plaques (90 to 121 HU) [23,24]. Patients with acute coronary syndromes were found to have a higher prevalence of noncalcified as compared with calcified plaque than stable coronary artery disease [25].

5. Conclusion

Cardiac CT is a rapidly developing and advancing technology. The diagnostic accuracy of Cardiac CT in the detection of coronary artery stenoses has been reported with very high negative predictive values by many investigators. The increase of radiation will reduce artifact, improve coronary artery visualization, although an excess of radiation exposure leads to cancer. Cardiac CT is useful in the invasive diagnosis of coronary artery disease for the stable and acute chest pain patients, especially who cannot be sufficiently evaluated by electrocardiography, echocardiography or cardiac MRI.
