Comparison of Indoor Localization Systems Based on Wireless Communications
Rejane Dalce, Thierry Val, Adrien Van Den Bossche
.
DOI: 10.4236/wet.2011.24033   PDF    HTML   XML   7,030 Downloads   13,330 Views   Citations

Abstract

Localization using a Wireless Sensor Network (WSN) has become a field of interest for researchers in the past years. This information is expected to aid in routing, systems maintenance and health monitoring. For example, many projects aiming to monitor the elderly at home include a personal area network (PAN) which can provide current location of the patient to the medical staff. This article presents an overview of the current trends in this domain. We introduce the mathematical tools used to determine position then we introduce a selection of range-free and range-based proposals. Finally, we provide a comparison of these techniques and suggest possible areas of improvement.

Share and Cite:

R. Dalce, T. Val and A. Bossche, "Comparison of Indoor Localization Systems Based on Wireless Communications," Wireless Engineering and Technology, Vol. 2 No. 4, 2011, pp. 240-256. doi: 10.4236/wet.2011.24033.

1. Introduction

The modern world is centered on communication and speed. We want to be informed as quickly and reliably as possible about our health, the state of our environment, our current safety. Wireless Sensor Networks (WSNs) are a type of network that has been developed as a response to this need for control. Their nodes aim to become part of our environment and, using embedded sensors, help us monitor the status of relevant parameters.

As the needs evolved, the attention has turned to mobile sensors, introducing a new constraint: the collected data must be mapped to a specific location in order to ensure a correct interpretation of the values. Let’s consider a mobile temperature sensor. When a measurement exceeds a set threshold, the system’s reaction will depend on the current location of the node. Each predefined zone will be associated to an acceptable temperature range according to the usual activities taking place in this space. For example, during winter, detecting a temperature below 4˚C in a bedroom hints a possible failure of the heater. On the other hand, the same value in a garage is perfectly normal. For the system to choose between alerting the system manager and ignoring the new value, the sensor’s location must be available.

Position aware network nodes can also help in routing [1]. The benefits of localization being shown, the question is: How do we determine it?

We are not the first group to find this topic interesting. Therefore, we plan on beginning with a description of the tools and methods generally used to solve the localization problem. We will focus on indoor solutions and ones that require minimum participation from the target. We will then introduce propositions that represent the current trends in location determination before identifying possible research areas and concluding this article.

2. Classical Localization Algorithms

When trying to localize an item, the first step is to define references. In this document, our references will be a subset of the network nodes. They will be aware of their location and will be referred to as “beacons”. Another term frequently used for this purpose in the literature is “anchor”.

The network’s deployment area can be either indoor or outdoor. In the first case, the radio signal mainly suffers from attenuation and reflections. In the latter, setting up links on high distances and maintaining them becomes a great challenge.

Once the references have been established, relative location determination becomes possible. According to the implementation choices, this operation can be executed either by the mobile node or by a central node with greater processing power. When the mobile node is responsible for calculating its own position, an efficient algorithm must be used. The other solution requires the installation of at least one localization server who will process requests from all nodes in the network.

The following subsections will introduce mathematical tools for positioning using 3 anchors as a reference.

2.1. Trilateration

This method requires the knowledge of the distance between the mobile and each beacon.

Let the anchors be B1, B2 and B3. M is the node we want to localize. The positions (xi, yi) of the beacons as well as the distances di are known. The relationship between M, B1 and B2 can be written as:

(1)

(2)

M is therefore located at the intersection of circles C1(B1,d1) and C2(B2, d2). A third circle generated using the information of B3 enables us to choose the correct position between the two solutions of the general case of two circles intersecting (Figure 1).

2.2. Triangulation

In order to apply this method, the mobile must be aware of the distance between two beacons and the angles α and β as shown in Figure 2. The law of sines yields:

(3)

(4)

Once the characteristics of the triangle are known, the coordinates of the third summit can be calculated. As stated while describing trilateration, the third beacon or an additional hypothesis will allow identification of the correct solution.

2.3. Fingerprinting

This method is a pattern-recognition technique. It comprises to steps: in the first step or learning stage, some characteristics of the environment are measured at different locations and the data is stored along with a spatial

Figure 1. Trilateration.

reference information. This step is also qualified as offline phase since it is usually performed before the activation of the localization service provided by the network.

The second step or online phase begins when the network is up and a mobile wants to determine its position. The same parameters are measured and the results are compared to the stored values.

The inherent modularity of fingerprinting enables researchers to work specifically on one phase or the other: hence the various propositions for selecting a position by comparing online and offline data.

According to the behavior of the measured characteristic through time, this method can be very interesting. Unfortunately, its cost in terms of setup time and data volume is high. Furthermore, any change in the configuration such as moving a beacon or modifying the environment, will imply creating a new database. In the case of a mobile WSN, the need for partial to complete updates will happen frequently.

2.4. Multilateration

Multilateration requires time information rather than distance. The time difference of arrival of a signal (TDOA) is used to determine position.

Figure 3 presents the case with the mobile being able to reach 4 beacons which are synchronized. The mobile node broadcasts a frame. Every beacon receiving the frame stores the local time of reception then calculates the difference between this time tag and the one provided by a set reference beacon. The collected time differences

Conflicts of Interest

The authors declare no conflicts of interest.

References

[1] R. Want, A. Hopper, V. Falc?o and J. Gibbons, “The Active Badge Location System,” ACM Transactions on Information Systems (TOIS), Vol. 10, No. 1, 1992, pp. 91- 102. doi:10.1145/128756.128759
[2] W. Fahs, “Diffusion d’Informations Partagees Entre Mobiles Cooperants Evoluant Sous une Meme Cellule d’un Reseau Sans fil Avec Infrastructure,” Ph.D. Dissertation, Univer- sité de Clermont-Ferrand, 2009.
[3] T. S. Rappaport, “Wireless Communications, Principles and Practice,” 2nd Edition, Prentice Hall, 1996.
[4] D. Lieckfeldt, J. You and D. Timmermann, “Characterizing the Influence of Human Presence on Bistatic Passive Rfid-System,” Wireless and Mobile Computing, Networking and Communications, Marrakech, November 2009, pp. 338-343.
[5] Specific Requirements Part 15.4: Wireless Medium Access Control (MAC) and Physical Layer (PHY) Specifications for Low-Rate Wireless Personal Area Networks (WPANs) Amendment 1: Add Alternate PHYs, IEEE Standard for Information Technology Telecommunications and Information Exchange between Systems, August 2007.
[6] F. Evennou, “Techniques et Technologies de Localisation Avancées Pour Terminaux Mobiles dans Les Environ- nements Indoor,” Ph.D. Dissertation, Université Joseph Fourier, Grenoble, 2007.
[7] J. Rabaey, F. Burghardt, D. Steingart, M. Seeman and P. Wright, “Energy Harvesting—A systems Perspective,” International Electron Devices Meeting, Washington, December 2007, pp. 363-366.
[8] http://en.wikipedia.org/wiki/Energy_harvesting
[9] M. Ghavami, L. B. Michael and R. Kohno, “Ultra Wideband Signals and Systems in Communication Engineering,” 2nd Edition, John Wiley & Sons Ltd., 2007. doi:10.1002/9780470060490
[10] T. K. K. Tsang and M. N. El-Gamal, “Ultra-Wideband (UWB) Communications System: An Overview,” 3rd International IEEE-NEWCAS Conference, August 2005, pp. 381-386.
[11] L. De Nardis and M.-G. Di Benedetto, “Overview of the IEEE 802.15.4/4a Standards for Low Data Rate Wireless Personal Data Networks,” Workshop on Positioning, Navigation and Communication, Hannover, April 2007, pp. 285-289.
[12] P. Bahl and V. N. Padmanabhan, “RADAR : An In-Build- ing RF-Based User Location and Tracking System,” Nineteenth Annual Joint Conference of the IEEE Computer and Communications Societies, Vol. 2, 2000, pp. 775-784.
[13] F. Dong, Y. Chen, K. Li and D. Guo, “A Calibration-Free Localization Solution for Handling Signal Strength Vari- ance,” Mobile Entity Localization and Tracking (MELT), Vol. 5801, 2009, pp. 79-90.
[14] H. Liu, H. Darabi, P. Banerjee and J. Liu, “Survey of Wireless Indoor Positioning Techniques and Systems,” IEEE Transactions on Systems, Man and Cybernetics, Part C: Applications, and Reviews, Vol. 37, No. 6, 2007, pp. 1067-1080.
[15] S. Lanzisera, D. T. Lin and K. S. Pister, “RF Time of Flight Ranging for Wireless Sensor Network Localization,” Workshop on Intelligent Solutions in Embedded Systems (WISES), Vienna, June 2006, pp. 1-12. doi:10.1109/WISES.2006.329127
[16] S. Schwarzer,M. Vossiek, M. Pichler and A. Stelzer, “Precise Distance Measurement with IEEE 802.15.4 (ZigBee) Devices,” IEEE Radio and Wireless Symposium, Orlando, March 2008, pp. 779-782.
[17] Z. Liang, I. Barakos and S. Poslad, “Indoor Location and Orientation Determination for Wireless Personal Area Networks,” International Workshop on Mobile Entity localization MELT, Vol. 5801, 2009, pp. 91-105.
[18] T. He, C. Huang, B. M. Blum, J. A. Stankovic and T. Abdelhazer, “Range-Free Localization Schemes for Large Scale Sensor Networks,” Proceedings of the 9th Annual International Conference on Mobile Computing And Networking, September 2003, pp. 81-95.
[19] D. Niculescu and B. Nath, “Ad Hoc Positioning System (APS),” Global Telecommunications Conference, Vol. 5, November 2001, pp. 2926-2931.
[20] W.-W. Ji and Z. Liu, “An Improvement of DV-HOP Algorithm in Wireless Sensor Networks,” International Conference on Wireless Communications, Networking and Mobile Computing, Wuhan, September 2006, pp. 1-4.
[21] L. Gui, A. Wei and T. Val, “A Two-level Range-free Localization Algorithm for Wireless Sensor Networks,” 2010 6th International Conference on Wireless Communications Networking and Mobile Computing (WiCOM), Chengdu, September 2010, pp. 1-4.
[22] L. Doherty, K. S. J. Pister and L. El Ghaoui, “Convex Position Estimation in Wireless Sensor Networks,” Twentieth Annual Joint Conference of the IEEE Computer and Communications Societies, Vol. 3, 2001, pp. 1655-1663.
[23] N. Bulusu, J. Heidemann and D. Estrin, “GPS-Less Low- Cost Outdoor Localization for Very Small Devices,” IEEE Personal Communications, Vol. 7, No. 5, 2000, pp. 28-34. doi:10.1109/98.878533
[24] F. Reichbach and D. Timmermann, “Indoor Localization with Low Complexity in Wireless Sensor Networks,” IEEE International Conference on Industrial Informatics, Singapore, August 2006, pp. 1018-1023. doi:10.1109/INDIN.2006.275737
[25] H. S. AbdelSalam and S. Olariu, “HexNet: Hexagon- Based Localization Technique for wireless Sensor Networks,” IEEE International Conference on Pervasive Com- puting, Galveston, March 2009, pp. 1-6. doi:10.1109/PERCOM.2009.4912871
[26] J. Yi, J. Koo and H. Cha, “A Localization Technique for Mobile Sensor Networks Using Archived Anchor Information,” Sensor, Mesh and Ad Hoc Communications and Networks, San Francisco, June 2008, pp. 64-72.
[27] http://www.decawave.com/
