Rehabilitation of an Existing Office Block
Tomasz Blaszczynski, Jacek Wdowicki
DOI: 10.4236/eng.2011.39107   PDF    HTML   XML   5,101 Downloads   8,907 Views   Citations


A new owner wishes to refurbish the analysed building assembled in 70’s to modern intelligent office block and to develop up to 3000 m2 of a new part. The old office building has been in use until late 80’s. First two floors are made as a monolithic and the rest are prefabricated as RC frame with the shear walls in both directions. All aspects, which came from the coexistence of an old and new part of the office block, will be the scope of an article. The BW for Windows program has been used for computations. In our paper models of shear wall structures in the modernised part as well as the new adjacent part have been shown. The short period of time necessary to obtain the results of the analysis has allowed for a fully interactive structural design. Many analyses have been created to estimate structural space stiffness for existing and new part of the building. Analysis showed, that existing part deflections were 7 times less then permissible one and after concrete grade of a new part has been changed, deflections for both parts were almost the same.

Share and Cite:

T. Blaszczynski and J. Wdowicki, "Rehabilitation of an Existing Office Block," Engineering, Vol. 3 No. 9, 2011, pp. 876-885. doi: 10.4236/eng.2011.39107.

Conflicts of Interest

The authors declare no conflicts of interest.


[1] PN-EN 206-1, PN-EN 206-1:2003, Concrete. Specification, Performance, Production and Conformity, in Polish.
[2] B. Lewicki, et al. “Buildings Build with Industrialized Methods,” in Polish, Arkady, Warszawa, 1979.
[3] O. Aksogan, H. M. Arslan and B. S. Choo, “Forced Vibration Analysis of Stiffened Coupled Shear Walls Using Continuous Connection Method,” Engineering Structures, Vol. 25, No. 4, 2003, pp. 499-506. doi:10.1016/S0141-0296(02)00192-X
[4] G. Q. Li and B. S. Choo, “A Continuous-Discrete Approach to the Free Vibration Analysis of Stiffened Pierced Walls on Flexible Foundations,” International Journal of Solids and Structures, Vol. 33, No. 2, 1996, pp. 249-263. doi:10.1016/0020-7683(95)00028-9
[5] J. Wdowicki, E. Wdowicka and T. B?aszczyński, “Integrated System for Analysis of Shear Wall Tall Buildings,” Proceeding of the Fifth World Congress on Habitat and High-Rise: Tradi-tion and Innovation, Council on Tall Buildings and Urban Habitat, Amsterdam, 1995, pp. 1309-1324.
[6] J. Wdowicki and E. Wdowicka, “System of Programs for Analysis of Three-Dimensional Shear Wall Structures,” The Structural Design of Tall Buildings, Vol. 2, No. 4, 1993, pp. 295-305. doi:10.1002/tal.4320020403
[7] J. Wdowicki, E. Wdowicka and T. B?aszczyński, “System of Programs for Dynamic Analysis of Shear Wall Tall Buildings,” Proceeding of the In-ternational Conference on Lightweight Structures in Civil En-gineering, Warsaw Univ. of Technology, Warsaw, 1995, pp. 440-445.
[8] E. Wdowicka, J. Wdowicki and T. B?aszczyński, “Seismic Analysis of the “South Gate” Tall Building Accord-ing to Eurocode 8,” The Structural Design of Tall and Special Buildings, Vol. 14, No. 1, 2005, pp. 59-67. doi:10.1002/tal.261
[9] Eurocode 1: Actions on struc-tures—Part 1-4: General Actions—Wind Actions on Structures, in Polish, PN-EN 1991-1-4: 2008.
