Comparison between the Isotope Tracking Method and Resistivity Tomography of Earth Rock-Fill Dam Seepage Detection
Mingjie Zhao, Hui Wang, Xiao Sun, Yao Zhang
DOI: 10.4236/eng.2011.34045   PDF    HTML   XML   5,558 Downloads   9,839 Views   Citations


This paper compares the different inversion results of three different earth rock-fill dam models with the actual leakage passages by performing isotope tracing tests and resistivity tomographic tests. The accuracy of the experimental results is evaluated, and the characteristics of these two methods are analyzed. As a result, some significant references are offered for earth rock-fill dam’s hidden defects detection. The experimental results show that the leakage and the direction of the seepage can be judged by isotope tracing tests, meanwhile, the degree of the leakage can be confirmed through the determination of the horizontal seepage velocity and the vertical seepage velocity, but it is difficult to properly determine the position of leakage passages and the range of leakage. Relatively speaking, the positions of the leakage passages can be accurately and directly displayed through resistivity tomographic tests. The experiment results show that the resistivity tomographic method is much better than isotope tracing method with regard to earth rock-fill dam’s hidden defects detection, and the resistivity tomographic method expresses much more convenience and much higher precision than isotope tracing method.

Share and Cite:

M. Zhao, H. Wang, X. Sun and Y. Zhang, "Comparison between the Isotope Tracking Method and Resistivity Tomography of Earth Rock-Fill Dam Seepage Detection," Engineering, Vol. 3 No. 4, 2011, pp. 389-399. doi: 10.4236/eng.2011.34045.

Conflicts of Interest

The authors declare no conflicts of interest.


[1] Z. Y. Liu and X. F. Song, “Use of Interwell Tracing in Studying the Distribution of Residual Oil in a Reservoir,” Journal of Jianghan Petroleum Institute, In Chinese, Vol. 21, No. 4, 1999, pp. 76-78.
[2] W. Song, J. L. Liu and M. Y. Yang, “Study on Erosion Process by the REE Tracer Method,” Advances in Water Science, Vol. 15, No. 2, 2004, pp. 197-201.
[3] K. Ma and Z. Q. Wang, “Summary of Tracer Method on Studies of Soil Erosion,” Research of Soil and Water Conservation, Vol. 9, No. 4, 2002, pp. 90-95.
[4] L. X. Yao, W. F. Chang and Y. Han, “Application of the Tracer Method of Hydraulic Engineering in the Survey Leakage,” Yellow River, No. 10, 2009, pp. 98-99.
[5] J. S. Chen, H. Z. Dong and Z. C. Fan, “Nature Tracer Method for Studying Leakage Pathway of By-Pass Dam Abutment of Xiaolangdi Reservoir,” Jourmal of Yangze River Scientific Research Institute, Vol. 21, No. 2, 2004, pp. 14-17.
[6] D. Yu, M. J. Zhao and J. G. Yang, “Experimental Research of Electrical Resistivity Tomography Detection Method in Leakage Passage of Earth Rock-Fill Dam,” Journal of Chongqing Jiaotong University (Natural Science), Vol. 29, No. 2, 2010, pp. 224-226.
[7] D. Li and K. H. Xiao, “High Den-sity Electrical Resistance Exploration in the Tiefengshan Tun-nel,” Chinese Journal of Engineering Geophysics, Vol. 3, No. 3, 2006, pp. 197-200.
[8] L. G. Zhang and J. Liu, “Application of High Density Resistivity Method to the Exploration of Karst Cave under Roadbed,” Soil Engineering and Foundation, Vol. 20, No. 5, 2006, pp. 69-71.
[9] S. K. Huang and Y. F. Ouyang, “Application of High Density Electrical Method to Karst Exploration,” Chinese Journal of Engineering Geophysics, No. 6, Vol. 17, 2009, pp. 720-723.
[10] X. Y. Lei, Z. W. Li and J. P. Zhe, “Research of High Density Resistivity in the Prospecting of the Soil Cave, Area of Coal Pits and Karst,” Progress in Geophysics, Vol. 24, No. 1, 2009, pp. 340-347.
[11] J. H. Deng, W. B. Li and D. S. Zhang, “Appli-cation of High Density Resistivity Method in Slope Investigation for Highway,” Geotechnical Engineering Technique, Vol. 22, No. 1, 2008, pp. 27-30, 35.
[12] Y. K. Men, G. H. Fan and A. L. Shao, “The Study of Integrated Detection Method to the Mined-Out Areas in Open Pit Iron Mine and Its Application,” Metal Mine, No. 5, 2010, pp. 124-127.
[13] S. P. Li, “The Application of the High Density Resistivity Method to the Prospecting for Bauxite Deposits,” Geophysical and Geochem-ical Exploration, Vol. 33, No. 1, 2009, pp. 8-9, 15.
[14] P. S. Zhang, J. S. Wu and S. D. Liu, “Testing with High Density Resistivity Method in Prevention and Cure for Mine Water Disaster and Its Applied Effect,” Chinese Journal of Coal So-ciety, Vol. 13, No. 2, 2007, pp. 165-169.
[15] H. L. Liu, Q. Y. Zhou and H. Q. Wu, “Laboratorial Monitoring of the LNAPL Contamination Process Using Electrical Resistivity Tomogra-phy,” Chinese Journal of Geophysics, Vol. 51, No. 4, 2008, pp. 1246-1254.
[16] Y. J. Su, X. B. Wang and J. Q. Luo, “The Ahaeological Application of Resistivity Tomography Method to Ditch Exploration on Sanxingdui Site,” Progress in Geophsics, Vol. 22, No. 1, 2007, pp. 268-272.
