On the Total Dynamic Response of Soil-Structure Interaction System in Time Domain Using Elastodynamic Infinite Elements with Scaling Modified Bessel Shape Functions ()
2. Elastodynamical Infinite Element with United Bessel Shape Functions
The idea and concept of the elastodynamic infinite elements with united shape functions (for short EIEUSF class infinite elements) are presented in [20,21]. Several EIEUSF formulations are discussed and have been demonstrated that the shape functions, related to nodes k and l (the nodes, situated in infinity, Figure 1, are not necessary to be constructed, because corresponding to these shape functions generalized coordinates or weights, see Equation (1), are zeros). The displacements in infinity are vanished, and these shape functions must be omitted. The theory used for the formulation of the EIEUSF class infinite elements has been published in detail in [6], and hence only summarize of the basic idea is demonstrated here. In [20] is mentioned why the EIEUSF class infinite elements are more general and powerful than the standard infinite elements.
The displacement field in the elastodynamical infinite
Figure 1. Local coordinate system of horizontal infinite elements (HIE).
element can be described in the standard form of the shape functions based on wave propagation functions as
(1)
where
are the standard shape displacement functions,
is the generalized coordinate associated with
, n is the number of nodes for the element and m is the number of wave functions included in the formulation of the infinite element. For horizontal wave propagation basic shape functions for the HIE infinite element, the local coordinate system of which is shown in Figure 1, can be expressed as:
(2)
where
are horizontal wave functions and
are Lagrange interpolation polynomial which has unit value at i-th node while zeros at the other nodes. For HIE infinite element the ranges of the local coordinates are:
and
. Here
assures the geometrical transformations of local to global coordinates.
(3)
and
(4)
Then Equation (1) can be expressed as
(5)
For horizontal wave propagation the basic shape functions for the HIE infinite element can be expressed using Bessel functions as follows:
(6)
where
are scaling modified Bessel functions of first kind. These functions can be written as
(7)
where
are standard Bessel functions of first kind. In Equations (6) and (7)
and
are constants, chosen in such a way that the length of the wave and the attenuation of the wave respectively, are identical with those, if Equation (2) is used. This means that the following two relations are valid:
or
(8)
where
is the wave length if
functions are used; π-if Bessel functions of first kind
are used (average distance between two zeros) to approximate the displacements in the infinite element domain, and:
(9)
because the Bessel functions of first kind attenuate proportionally to
. The zeros of Bessel functions play a dominant role in applications of these functions [23] and demonstrate their oscillatory. Although the roots of Bessel functions are not generally periodic, except asymptotically for large
, such functions give acceptable results for simulation of wave propagation. And what is more, using Bessel functions one can approximate change of the wave length in the far field region. If the element has four nodes and eight DOF (the simplest twodimensional plane element [6]) only four shape functions can be used to approximate the displacements, related to one frequency. These functions can be written as:
(10.a)
(10.b)
(11.a)
(11.b)
and
(12.a)
(12.b)
(13.a)
(13.b)
where in the general case
.
If rotational DOF are used then the element has four nodes and 1o DOF. Two additional shape functions must be used, written as:
(14)
and
(15)
Here
and
are Bessel functions of first kind.
The function
is linear if no mid-nodes. Finally, if mid-node on the side i-j is used, then the Lagrange interpolation polynomials must be quadratic. Scaling modified Bessel functions of first kind, in accordance with Equation (6) (
and
), are illustrated in Figure 2.
The continuity along the artificial boundary (the line between finite and infinite elements, see Figure 3 line
and line
) is assured in the same way as between two plane finite elements [21]. The application of the proposed infinite elements in the Finite element method is discussed below.
Using the procedure, given in details in [6] and briefly described here, mapped EIEUSF infinite elements, based on scaling modified Bessel functions, can be formulated, based on Equation (16)
(16)
where
.
3. Stiffness and Mass Matrices
The matrices
and
, related to the near field of the Soil-Structure System (SSS) can be written as
(17)
and
(18)
and those related to the far field
and
, i.e. obtained for the proposed infinite elements, as
(19)
and
(20)
where N, B and D are shape function matrix, strain-displacement matrix and stress-strain matrix, respectively.
The matrices
and
are calculated using the principle of the virtual work.
If Bessel functions are used, the first derivative of
(The Taylor series indicate that by
and
the derivative of
) can be expressed) is
.
The general form of the equations of motion in time domain can be written as
(21)
where
and
are mass, damping and stiffness matrices, respectively, and
is nodal force vector.
The equations of motion of the entire SSS, using the Substructural approach with EIEUSF infinite elements, based on scaling modified Bessel functions, transformed into time domain by inverse Fourier transformation, are
(22)
if massless far field is assumed. In Equation (21)
and
are respectively displacement and force vectors, and
and
are matrices of mechanical characteristics of the far field soil region. Here
(23)
can be assumed as a Duhamel integral or more generally as a convolution integral, for
.
Equation (23) is a standard convolution of two functions, given in vector forms, namely
and
. Here the vector components of
can be taken in case of seismic events from seismograms.
If rotational acceleration of the base is possible, than Equation (22) becomes
(24)
where
.
The matrix
assures the transformation of the nodal unit displacement impulse vector
, applied at moment
, to a nodal force vector
at moment
and can be treated as a transformation matrix, the general form of which can be written as
. This matrix in the present case can be expressed as
(25)
where
can be treated as a stiffness matrix, the components of which can be calculated from
.
The vector
denotes the vector of interaction forces of the unbounded soil acting at nodes b, the nodes situated on the artifitual boundary. These forces are acting as a result of the relative motion between the unbounded soil and the total motion of the near field, see Figure 3, expressed in vector forms as
or
.
For discrete time points the vector
is calculated, using Equation (26) as
(26)
If the force vector, i.e.
, at moment
is known, i.e.
(27)
at moment
, the force vector
can be obtained using
(28)
or if
is small time interval using the approximation
(29)
If Equation (23) is expressed as
(30)
then the trigonometric identity
can be used and finally
(31)
Using the proposed infinite elements, the resulting element stiffness matrices related to the far field are inexpensive to calculate and the global stiffness matrix has relatively small bandwidth. It is reasonable to expect similar results in SSI simulations, based on EIEUSF infinite elements with modified Bessel shape functions to those when EIEUSF infinite elements are used.
The nodal displacement vector at moment t can be calculated using step-by-step method, applied to Equation (23), given in time domain. Such a computational technology is demonstrated in the next Section.
4. Numerical Example
Structure with rigid strip foundation resting on a homogeneous half-space is modeled as shown in Figure 3, and the far field is descretized by elastic springs with stiffness
(model 1), by elastic springs with stiffness
(model 2), by massless EIEUSF infinite elements with one wave frequency [20] (model 3) and by massless infinite elements with Bessel shape functions [20] (model 4).
Horizontal harmonic displacements with period
and amplitude
are applied on the nodes as shown in Figure 3. The geometry of the model and the material parameters are given in [6].
The results for the first 4 natural periods, corresponding to the models and max displacement of node S, are given in Table 1. The time history of the displacements of node S, see Figure 3, between 9.1 s and 9.5 s are illustrated in Figure 4.
The numerical example shows that, if EIEUSF infinite elements or infinite elements with Bessel shape functions are used, the position of
can be translated starting from
(see
in Figure 3) to
without significant influence on the results. However, if elastic springs are used, the results are significantly affected. Such a reduction of the near field demonstrates the effectiveness of the proposed infinite elements.
5. Conclusions
In this paper a formulation of elastodynamical infinite element, based on scaled Bessel shape functions, is appropriate for Soil-Structure Interaction problem, and the computational concept and the corresponding equations
Figure 4. Time history of the displacements of node S.
Table 1. Natural periods, corresponding to the models and max displacements of node S.
of motion of the entire SSI system are presented. This element is a new form of the infinite element, given in [6,21]. The base of the development is new shape functions, obtained by modification of the standard Bessel functions of first kind
by appropriately chosen scale factor. The stiffness matrices of these infinite elements are calculated by EIEUSF matrix module, and developed by the same author.
The numerical example shows the computational efficiency and accuracy of the proposed infinite elements. Such elements can be directly used in the FEM code. The results are in a good agreement with the results, obtained by EIEUSF infinite elements. Moreover, the use of scaling modified Bessel functions in the construction of the shape functions leads to computational efficiency in the stage of the calculation of the stiffness and mass infinite element coefficients.
The formulation of 2D horizontal type infinite elements (HIE) is demonstrated, but by similar techniques 2D vertical (VIE) and 2D corner (CIE) infinite elements can also be formulated. It was demonstrated that the application of the elastodynamical infinite elements is the easier and appropriate way to achieve an adequate simulation (2D elastic media) including basic aspects of SoilStructure Interaction. Continuity along the artificial boundary (the line between finite and infinite elements) is discussed as well and the application of the proposed elastodynamical infinite elements in the Finite element method is explained in brief.
