Interferometry Analysis of Cellophane Birefringence

Abstract Full-Text HTML XML Download Download as PDF (Size:629KB) PP. 337-341
DOI: 10.4236/opj.2013.36052    3,437 Downloads   5,293 Views   Citations

ABSTRACT

This paper reports on a simple approach of determining the ability of a transparent material, such as cellophane to rotate the direction of polarization of a light beam. In order to determine the birefringence of such a material, a Mach-Zehnder interferometer is used to generate interference patterns when the cellophane sheet is mounted on one arm such as to intercept a portion of the laser beam. The recorded interferograms show a phase shift which is calculated to be 0.98π radians. By rotating the cellophane sheet on the object beam, the fringe separation is measured for different angles and the values used to calculate the ordinary and extraordinary refractive indices as 1.4721 ± 0.0002 and 1.4680 ± 0.0002 respectively at 632.8 nm wavelength. A surface error of approximately λ/16 (peak to valley) is measured from the recorded interferograms. Because of its sufficient birefringence and small thickness of 24 μm, cellophane can be used to fabricate special polarization pupil masks by cutting and aligning different cellophane structures appropriately.

Conflicts of Interest

The authors declare no conflicts of interest.

Cite this paper

D. Kinyua, G. Rurimo, P. Karimi, S. Maina and C. Ominde, "Interferometry Analysis of Cellophane Birefringence," Optics and Photonics Journal, Vol. 3 No. 6, 2013, pp. 337-341. doi: 10.4236/opj.2013.36052.

References

[1] E. Fahy and M. Macconail, “Optical Properties of ‘Cellophane’,” Nature, Vol. 178, No. 4541, 1956, pp. 1072-1073. http://dx.doi.org/10.1038/1781072b0
[2] L. Keigo, “Complementary Cellophane Optic Gate and Its Use for a 3D iPad without Glasses,” The Review of Scientific Instruments, Vol. 83, No. 4, 2012, Article ID: 043710. http://dx.doi.org/10.1063/1.4705734
[3] B. Augusto, F. Elena, F. Jorge and N. Cristian, “Birefringence of Cellotape: Jones Representation and Experimental Analysis,” European Journal of Physics, Vol. 31, No. 3, 2010, pp. 551-561.
http://dx.doi.org/10.1088/0143-0807/31/3/012
[4] L. Keigo, “Cellophane as a Half-Wave Plate and Its Uses for Converting a Laptop Screen into a Three-Dimensional Display,” The Review of Scientific Instruments, Vol. 74, No. 8, 2003, pp. 3636-3639.
http://dx.doi.org/10.1063/1.1592879
[5] G. Ortiz, P. Olivases and V. Sanchez, “Cellophane Film as Half Wave Retarder of Wide Spectrum,” Optical Materials, Vol. 17, No. 3, 2000, pp. 395-400.
http://dx.doi.org/10.1016/S0925-3467(00)00102-6
[6] M. Hernandez, A. Juarez and R. Hernandez, “Interferometric Thickness Determination of Thin Metallic Films,” Superficies Vacio, Vol. 9, 1999, pp. 283-285.
[7] K. Betzler, A. Grone, N. Schmindt and P. Voigt, “Interferometric Measurement of Refractive Indices,” The Review of Scientific Instruments, Vol. 59, 1988, pp. 4652-4653. http://dx.doi.org/10.1063/1.1139853
[8] M. Abraham, “Refractive Index and Thickness Determination of Transparent Films: An Interference Method,” Electronics and Optics, Vol. 109, 1983, pp. 93-102.
[9] H. Eugene, “Optics,” 2nd Edition, Addison-Wesley Publisher, Boston, 1987, pp. 334-347.
[10] E. Mach, “The Principles of Physical Optics,” Dove Publications, New York, 1973, pp. 170-172.
[11] F. L. Pedrotti and L. S. Pedrotti, “Introduction to Optics,” 2nd Edition, Prentice Hall, Upper Saddle River, 1993, pp. 224-244.
[12] N. Harrick, “Determination of Refractive Index and Film Thickness from Interference Fringes,” Applied Optics, Vol. 10, No. 10, 1971, pp. 2344-2349.
http://dx.doi.org/10.1364/AO.10.002344
[13] S. F. Pereira and A. S. van de Nes, “Super Resolution by Means of Polarization, Phase and Amplitude Pupil Masks,” Optics Communications, Vol. 234, 2004, pp. 119-124. http://dx.doi.org/10.1016/j.optcom.2004.02.020
