Interactive Kalman Filtering for Differential and Gaussian Frequency Shift Keying Modulation with Application in Bluetooth ()

Mahdi N. Ali, Mohamed A. Zohdy

Electrical and Computer Engineering Department, Oakland University, Rochester, USA..

**DOI: **10.4236/jsip.2012.31009
PDF
HTML XML
7,091
Downloads
11,454
Views
Citations

Electrical and Computer Engineering Department, Oakland University, Rochester, USA..

Some applications are constrained only to implement low cost receivers. In this case, designers are required to use less complex and non-expensive modulation techniques. Differential Quadrature Phase Shift Keying (DQPSK) and Gaussian Frequency Shift Keying (GFSK) can be non-coherently demodulated with simple algorithms. However, these types of demodulation are not robust and suffer from poor performance. This paper proposes a new method to enhance the performance of DQPSK and GFSK using Interactive Kalman Filtering (IKF) technique, in which a one Unscented Kalman Filter (UKF) and two Kalman Filters (KF) are coupled to optimize the demodulated signals. This method consists of simple but very effective algorithms without adding complexity to the demodulators comparing to other very complex methods. UKF is used in this method due to its superiority in approximating and estimating nonlinear systems and its ability to handle non-Gaussian noise environments. The proposed method has been validated by creating a MATLAB/SIMULINK Bluetooth system model, in which the IKF is integrated into the receiver, which implement both DQPSK and GFSK, and run simulation in Gaussian and Non-Gaussian noise environments. Results have shown the effectiveness of this method in optimizing the received signals, and that the UKF outperforms the Extended Kalman Filter (EKF).

Share and Cite:

Ali, M. and Zohdy, M. (2012) Interactive Kalman Filtering for Differential and Gaussian Frequency Shift Keying Modulation with Application in Bluetooth. *Journal of Signal and Information Processing*, **3**, 63-76. doi: 10.4236/jsip.2012.31009.

1. Introduction

Receivers with noncoherent demodulation have simple structures, but they don’t have robust performance [1-3]. Simple noncoherent demodulators are attractive in applications where cost is a concern. For example, in Bluetooth protocols [4], noncoherent detection of GFSK and variants of Differential Phase Shift Keying (DPSK) are specified due to their simplicity and low costs. Although these non-optimal techniques are sufficient in low noisy channels, they may suffer performance degradations in very noisy environments.

In order to optimize the performance of the noncoherent demodulation, some complex Maximum Likelihood Sequences Estimator (MLSE) is utilized. An efficient method of implementing this estimation process is through the usage of the very complex Viterbi algorithm that searches the paths through the state trellis for the minimum Euclidean distance path [1]. It was shown that using the Viterbi decoder in Bluetooth receiver achieved very superior performance, but added more complexity, comparing to the noncoherent demodulation that consists of Limited Discriminator with integrating and dump filter [5].

DQPSK is one form of DPSK. It is a memoryless, and a discontinuous phase modulation, in which the current binary sequence is modulated independently of the previous sequences. GFSK is a subclass of Continuous Phase Modulation (CPM), and an attractive modulation in many applications due to its enhanced spectral properties. In modulations, where phase is not continuous, poor spectral efficiency is a real issue. Discontinuities and abrupt changes in phase cause this poor performance, making CPM a more favored scheme [2,6]. GFSK is a modulation with memory, in which the current transmitted signal depends on the current and previous binary sequences. In DQPSK, the phase is constant over a one symbol interval, while in GFSK the phase varies continuously over the symbol period [7]. Both DQPSK and GFSK can be detected non-coherently, which results in simplified transceivers [8].

In the latest Bluetooth specifications, two types of modulation schemes are specified. The first one is the GFSK, which is a form of Continuous Phase Frequency Shift Keying (CPFSK), and hence CPM [9]. It is used in the Basic Data Rate (BDR), with transmission rate at 1 Mbps. The other type is the Differential Phase Shift Keying (DPSK), which is used in the Enhanced Data Rate (EDR) with two variants, π/4-DQPSK and 8DPSK. The transmission rates are 2 Mbps for EDR using π/4-DQPSK and 3 Mbps using 8DPSK [4]. Data are transmitted in frames of 625 µs time slots. Each frame is divided mainly into Access Codes (AC) and Payloads. In the EDR, the AC is modulated using one of the DPSK variants, while the payload is modulated using GFSK. No equalization requirements are specified in Bluetooth protocols in order to preserve the low complexity of the system, leaving this area open for researchers to propose efficient equalization and optimization methods that improve the performance of the system, but without inducing much costs.

Significant amount of researches have been conducted to optimize the performance of the DQPSK and GFSK noncoherent demodulation. A. Soltanian and R. E. Van Dyck showed that in typical Bluetooth indoor applications, the noncoherent limiter-discriminator with integrate and dump filter receiver, without equalization, achieves reasonable performance; but this is not the case for the outdoor and large indoor applications, where the signal needs to be more robust. They suggested the usage of Viterbi receiver to get optimum results for such applications [5]. In [9], N. Ibrahim, L. Lampe, and R. Schober presented a receiver design for a GFSK demodulator based on Laurent’s decomposition. They developed a Non-coherent Decision Feedback Equalizer (NDFE) and showed that it achieved a robust performance comparing to other equalization methods. In their method, they handled the nonlinearity in the modulation by transforming it into linear using Laurent’s decomposition.

M. Nafie, A. Gatherer, and A. Dabak presented a nonadaptive a fractionally sampled Decision Feedback Equalizer (DFE) to be added after the discriminator to enhance the performance of noncoherent GFSK receivers. The proposed DFE was non-adaptive, and they proposed this equalizer to be trained off line at a certain SNR and then this will be used in reception [10]. Harry Leib presented his work that considered an optimal noncoherent demodulation of DPSK when the receiver has partial knowledge of the transmitted data. They proposed A Maximum Likelihood (ML) noncoherent receiver in [11]. The same technique was implemented for GFSK signals in [12].

Implementing Kalman Filtering to enhance the performance of noncoherent continuous and differential phase demodulation have been proposed in several articles. In [13,14], Gal, Campeanu, and Nafornita proposed a method of applying Extended Kalman Filtering in the noncoherent demodulation of CPM and CPFSK respectively. In [15], O. Loffeld utilized the EKF in the demodulation of noisy phase or frequency of sinusoidal signals of unknown amplitude in the presence of an Additive Wideband Gaussian Noise (AWGN). He assumed that the state space model of the unknown phase and amplitude were known. Those Proposed papers utilized linearization technique on the system before using the EKF.

In 1960, Rudolf E. Kalman presented his Kalman Filter method in [16]. KF is an estimator, in which it estimates the states in linear dynamic systems by minimizing the Minimum Mean Squared Error (MMSE). Kalman invented this based on modifying Wiener-Kolmogorov filter, which was derived in 1940 [17]. KF is originated from Baye’s probabilistic theory, in which if good number of past samples are known, the future samples can be predicted and updated based on the continuously collected results [18]. Techniques have been proposed to modify KF to be applied to nonlinear systems. For example, EKF has been proposed in nonlinear systems estimations by linearizing the estimated variables through deriving Jacobian matrices. However, EKF may not be a good choice in system with high nonlinearity, or systems that are very difficult to calculate their Jacobian matrices [19].

All the referenced techniques as mentioned thus far are either very complex, or suffer from inadequacy in handling nonlinearly and non-Gaussian noise environments. A better method to approximate nonlinear systems and apply Kalman filtering equations to them was proposed by S. Julier and J. Uhlmann [20]. UKF was derived based on the unscented transformation (UT) concept, which is used to approximate random variables distributions that are going through nonlinear transformations without a need to calculate the probability density functions (pdf) of the nonlinearly transformed variables. UKF has been demonstrated to be very effective in applications when dealing with nonlinear dynamic systems and non-Gaussian types of noises comparing to other filtering techniques [21]. Several types of UKF methods have been developed based on different techniques of UT. These techniques include the General Unscented Transformation, the Scaled Unscented Transformation, the Reduced Sigma Point, and the Spherical Simplex Unscented Transformation [22-25]. In [26], M. Ali and M. Zohdy proposed using UKF in the equalization of CPFSK. They showed that UKF outperformed EKF when both implemented in the CPFSK.

In this paper, we are proposing the implementation of IKF to enhance the performance of the noncoherent demodulation of DQPSK and GFSK. It will be shown that UKF has superior performance in approximating nonlinear systems, and in handling non-Gaussian noise than the already existed EKF methods. This proposed method is an attractive one in the sense that it has simple algorithms so that not that much complexity is added to the receivers comparing to the optimum demodulation. Simulation will be run on a developed MATLAB/SIMULINK model representing Bluetooth system. Results will be compared to those generated by the same model before the implementation of this method, and when using EKF.

This paper has been organized as follow. Introduction is presented in the Section 1. Section 2 will details the new method of the unscented transformation, and how to apply it in UKF. Section 3 will discuss the signal descriptions of DQPSK and GFSK, and Section 4 will detail the system models of both. Section 5 will explain the IKF algorithms. In Section 6, the simulation and results will be listed. Section 7 lists the conclusion.

2. Unscented Transformation and Unscented Kalman Filter

The UT does not approximate the nonlinear process and observation functions. It approximates the statistics (mean and covariance) of the state variable which has dimension by carefully choosing a deterministic set of sample points and their corresponding weights which have dimensions. These sigma points and their associated weights are chosen carefully to capture accurately the actual mean and covariance of the state variables, and when the sampled mean and covariance are propagated through a nonlinear system, the a posteriori mean and covariance of the state variables can be estimated accurately up to the 3^{rd} order of any nonlinearity [20]. The statistics of the random variables can also be approximated for higher nonlinearity (4^{th} order and up) but with some errors. Figure 1 illustrates the principle behind the UT when some deterministic points are undergoing nonlinear transformation.

2.1. Choosing Sigma Points

There is no single method of choosing sigma points that guarantees global optimization of a system. Rather, many methods have been proposed in which each one has advantages and disadvantages over the others. Simon Julier proposed the Scaled Unscented Transformation (SUT) in [23] to be able to control the sigma points without the possibilities of the covariance to become non-positive semi-definite. In the SUT, the sigma points are calculated as follow:

Figure 1. Nonlinear transformations using unscented transformation.

(1)

where, , and and are the associated weights of these sigma points. The scaling factor is a tool to scale the sigma points towards or away from the mean. It should be noted that there is no general way to propose the values of the scaling factors. In each application, these values should be chosen to reduce the estimation errors for their specific problems. As an example, for Gaussian distributions, the scaling factors can be set to 2, 0.001, and 0 respectively for optimum estimation [21].

2.2. The Unscented Kalman Filtering

The UKF is a novel method that was proposed in [20] to propagate the mean and covariance of a random variable through nonlinear systems using the unscented transformation in order estimate the a posteriori mean and covariance. The following lists the steps for the UKF algorithm based on the SUT.

2.2.1. Nonlinear System Equations

A nonlinear system can be represented as:

(2)

(3)

Equation (2) models the system process model, where represents the states to be estimated, represents the input, and represents the process noise that has zero mean and covariance. Equation (3) models the observation model, where represents the measurement noise, which has zero mean and covariance.

2.2.2. Initialization and Sigma Points Calculation

The state vector and process covariance matrix need to be initialized as follow:

(4)

(5)

where. Equation (1) can be used to derive deterministic sigma points, which can be written as:

(6)

2.2.3. Time Update Equations

The sigma points in Equation (6) are propagated through the nonlinear process function in Equation (2) to give:

(7)

The sampled predicting mean and covariance of the state variable are calculated in the next two equations.

(8)

(9)

2.2.4. Measurement Update Equations

In order to derive the measurement update equations, the sigma-point states as derived in Equation (7) need to be propagated in the nonlinear measurement model in Equation (3).

(10)

The output sampled mean and covariance are captured as follow:

(11)

(12)

The cross covariance of the state and measurement can be calculated as:

(13)

Using the conventional KF equations, we can calculate Kalman gain as:

(14)

where, and are derived in Equations (12) and (13) respectively. The Kalman gain as derived in Equation (14) can be used in the following equation to calculate the updated a posteriori mean of the states.

(15)

Finally, the update covariance can be expressed as:

(16)

3. π/4 DQPSK and GFSK Signal Description

3.1. π/4 DQPSK Signal Description

The π/4-DQPSK is a version of DQPSK, but shifted by π/4. For simplicity we refer to π/4-DQPSK as DQPSK throughout this paper. Its transmitted signal can be represented as [27]:

(17)

where represents the carrier-modulated signal,_{ }is the information-carrying phase that mapped to a symbol, and are the symbol energy and duration respectively. and is the number of symbols, which is 4 in the case of DQPSK. At the dynamic behavior of the phase can modeled as:

(18)

where the addition is modulo. is the value, which results from mapping the binary sequences to the phase representation. Thus, 11, 01, 00, 10 sequences are mapped to respectively. Equation (18) shows the dynamic transition when phase is changing from current transmitted symbol to the next one. The Inphase and Quadrature components (complex envelops) of the transmitted signal of the symbol are determined as follow:

(19)

(20)

The Inphase and Quadrature are functions of the phase which is in turn functions of the previous state and the current input. This is modulated this way so that the only information needed at the demodulator side is the difference between the consecutive received phases, which enable simpler noncoherent demodulation. The In-phase and Quadrature are passed through pulse shape filters to smooth the pulses and conserve the bandwidth. When pass through these filters, the resulted pulses are represented as:

(21)

(22)

There are several forms of the pulse shapes, which can take the forms of Gaussian, Raised Cosine, and others. When these components are multiplied by the carrier, the resulted baseband modulated signal is:

(23)

3.2. GFSK Signal Description

The transmitted carrier-modulated GFSK signal can be represented in the following format [12,27]:

(24)

The complex baseband waveform of this signal can be expressed as:

(25)

where the phase can be represented as:

(26)

where, represents the carriermodulated signal, is the time-varying phase of the carrier, is the symbol energy, is the symbol duration, and is the carrier frequency. The digital sequence represents the M-ary information symbols that can take the following symbol format , and for binary sequences,. h is the modulation index. The first term on the right side of Equation (26) models the phase history. is the phase response, which is derived by integrating a pulse, and is the length of this pulse (per unit). is defined as the instantaneous frequency of. The shape of determines the smoothness of the transmitted carrying information phase [28]. For example, in the case of GFSK, is shaped using Gaussian pulses instead of rectangular as this the case in CPFSK. There are Different pulse shapes, such as Raised Cosine (RC), and Gaussian Minimum Shift Keying (GMSK), etc.

4. π/4 DQPSK and GFSK System Description

In Kalman Filtering, two steps are performed; prediction and update. It is important that the received signal to be predictable in order to use Kalman Filters. Thus, the system under study needs to be modeled to allow performing prediction. Both DQPSK and GFSK dynamic systems will be modeled nonlinearly, and transformed into state space format so that Kalman filtering can be applied. In the noncoherent DQPSK, the current phase is a function of the previous phase and the current input, making it possible to do the prediction task of the next phase. In the case of GFSK, or any other CPM, Kalman Filtering can be an attractive technique since the transition in phase is continuous, and the changes do not occur abruptly, making the prediction step possible also.

4.1. π/4 DQPSK Dynamic System Description

Before the signal goes through decoding and decision state, it goes through the proposed Interactive Kalman Filtering for optimization. In order to apply Kalman Filtering, we need first to derive the state space equations that describe the system. The RC shaping pulse _{ }causes the phase response to be nonlinear. Therefore, at, the phase can be represented nonlinearly using Euler’s formula as:

(27)

where the delta change representing the change from one phase to the next one can be approximated as:

(28)

Equation (28) is the first order difference equation of the phase. is a discrete value and constant over one symbol duration. represents the symbol sequences, and is the process noise, which is assumed to have zero mean and variance. is the step size, which is treated as a fixed number in this paper, that determines the change value from to. The smaller this value is, the smaller the nonlinear approximation error is. is the rate of the change (slope) at. If a rectangular pulse shape was considered as it is the case in CPFSK, than equation (27) can be modeled linearly as [13]. However, for GFSK, this behavior is nonlinear, and Equation (27) can be represented as:

(29)

4.1.1. State Transition Model

There are two states in the system, the phase and the difference equation that need to estimated. The following equations represent the dynamic system of the DQPSK in state space format.

(30)

(31)

These can be written in the following matrix format:

(32)

In order to calculate, some a priori knowledge of at is needed. Thus, Equation (28) can be re-written as:

(33)

where is the prediction of the phase at having knowledge of the phase up to. can be estimated using two coupled Kalman Filters, as it will be explained in Section 5.

4.1.2. Measurement Models

When transmitted through an ideal channel, which is corrupted by AWGN, the Inphase and Quadrature components of the received signal at can be represented as:

(34)

where and are the measurement noise of the Inphase and Quadrature components respectively.

4.2. GFSK Dynamic System Description

GFSK is different from the DQPSK in a sense that it is a frequency shift keying modulation, and its phase is changing continuously during a symbol transmission [7]. There are two states to estimate in this system, the continuously changing phase and the difference equation, where is the input sequences. The dynamic equations can be represented as:

(35)

(36)

Equation (35) states that when the state changes from toover a symbol with duration, can be determined using Euler’s formula by adding the change in the phase to the previous phase. is the step size, and is the process noise. This dynamic system can be modeled nonlinearly as:

(37)

At the receiver, the signal can be modeled as:

(38)

where.

4.2.1. State Transition Model

The dynamic system of the phase and difference equation of the GFSK can be written as:

(39)

(40)

In a matrix format, (39) and (40) can be represented as

(41)

4.2.2. Measurement Model

When transmitted through an ideal channel with AWGN, the Inphase and Quadrature components of the received signal at can be represented as:

(42)

4.3. π/4 DQPSK and GFSK Dynamic System Description

There are communication systems that implement multiple modulation schemes, such as WIFI, Bluetooth, etc. Figure 2 represents a receiver that implements both DQPSK and GFSK, similar to the modulation schemes as specified in Bluetooth communications [4]. This figure depicts a functional blocks of the demodulator along with the proposed IKF interface. The DQPSK part of the demodulator processes the AC and Headers portion of the frames, while the GFSK part of the demodulator processes the Payloads portion of the frames. As it will be explained in the next section, the two KFs calculate the a priori phase and feed it into the UKF. In its turn, UKF uses this a priori and knowledge of the noise characteristics, and apply its simple algorithms to estimate the received signal components, before it feeds it into the decoding and decision devices for further processing.

Next, the state space equations for both DQPSK and GFSK systems are presented, which include 4 states, and 4 outputs.

Figure 2. The baseband DQPSK and GFSK receiver with the integrated Kalman filtering.

4.3.1. State Transition Model

(43)

4.3.2. Measurement Model

The measurement equations can be written as follow:

(44)

5. Interactive Kalman Filtering

Dual estimations concept has been explored in several researches in different applications. In [29], D. Labarre et al. proposed to take advantage of the so-called instrumental variable (IV) techniques to estimate both the received signal and the associated parameters. They proposed using two conditionally linked Kalman Filters in order to avoid using an EKF to estimate both states and parameters. The first KF uses a new observation to estimate the incoming signal, while the second KF uses this estimated signal to estimate the coefficient parameters. In [30], A. Jamoos, A. Abdo, and H. Nour used similar technique to jointly estimate channel coefficients and parameters using two coupled Kalman Filters in the estimation of rapidly time-varying Rayleigh fading channels in Orthogonal Frequency Division Multiplexing (OFDM) mobile wireless system. Thus, each time a new observation is available, the first filter uses the latest estimated parameters to estimate the signal, while the second filter uses the estimated signal to update the parameters.

5.1. Phase Prediction

This joint estimation method will be utilized to predict the a priori phase based on the past measured received signals, and feed this predicted value into in UKF to use it in its algorithm. From Equation (29), the phase is predicted based on the previous value and the change as triggered by the current input, which is equivalent to. Thus, in order to calculate, we need to have knowledge of. At the mean time, we need to know in order to calculate. The dual estimation is proposed to handle this case to predict the phase. The phase is replaced by _{ }in Equation (29), which can be written as:

(45)

This a priori can be predicted recursively using the following formula:

(46)

where is the prediction coefficients, is the so called driving process and it is assumed to be zero-mean noise with variance, and is the order. This is called joint estimation [18], since both the phase and their coefficients need to be estimated, and they depend on each others. Two KFs are proposed in order to perform the estimation, which allow the analysis to be run linearly and avoid using any of the nonlinear approximation methods.

KF1 estimates the phases, while KF2 estimates their coefficients. Figure 3 shows a layout of this proposed IKF method.

5.2. Estimation of the Phase Values

Let. Equation (46) can be put in the following state space format:

(47)

(48)

When, these matrices are defined as:

The goal is to estimate the phase at,_{ }given _{ }observations of as well as estimating the output also. The a posteriori is defined as:

(49)

where, is called innovation process and is defined as. Its covariance can be defined as:

(50)

The so called a priori error covariance matrix can be calculated recursively as:

(51)

is called the Kalman gain, and is calculated as:

(52)

The so called a posteriori covariance is updated as follow:

(53)

Finally, the output of KF1 is the predicted phase and can be expressed as:

(54)

The estimated phase will be fed into KF2 as the observed values and used in the coefficients estimation, and will be used as the a priori and fed into the UKF. The state vector and its covariance can be initialized as and.

5.3. Estimation of the Coefficients

The state vector that was estimated in KF1 is used

Figure 3. Interactive Kalman filtering.

as the observed value to KF2. In order to estimate the coefficients from the estimated phase, Equations (49) and (54) are combined as:

(55)

For the 4^{th} order system, the phase and coefficients vectors are defined as

and respectively. Assuming that the phase signal is stationary or changing very slowly from the current value to the next one, it is possible to assume that the coefficients to be approximately time invariant over a short period of time. In this case they can be written as:

(56)

Now we are ready to define the state space equations for KF2 to estimates the coefficients as:

(57)

(58)

where become the observed values, and are the states to be estimated. The covariance of the process can be calculated as:

(59)

The coefficients can be recursively computed as:

(60)

where the Kalman gain and the update state covariance matrix can be calculated as:

(61)

(62)

In the same manner, the initial state and its covariance can be initialized as: and.

6. Simulation and Results

6.1. MATLAB/SIMULINK Bluetooth Model

A Bluetooth model has been created to implement and validate the proposed method. This model was created in the MATLAB/SIMULINK environments [4]. The transmitted signal power is set to 100 mw representing Bluetooth class 1 devices, which can communicate up to 100 meters. The model consists of three parts; the transmitter, the channel, and the receiver. In the transmitter, the data go through the source and channel coding. The data are structured in frames. In the simulation runs, data representing actual speech signals have been processed. Data are organized in frames. Each frame contains 72 bits for Access Codes (AC), 56 bits for Headers, and 240 bits for the payloads, which makes up a total of 366 bits per frame. The 126 bits representing the AC and Headers are modulated using _{ }DQPSK in this model, and the 240 bits are modulated with GFSK, and transmitted over an AWGN channel in 625 µs time slots. In some of the simulation runs, non-Gaussian channel was used.

The receiver was simulated so that the frame was divided into two sections. The first section is processed by the DQPSK portion of the demodulator (bits 1 - 126), while the other sections was build with the GFSK demodulator to process bits 127 - 366. The rest of the blocks in the receiver were simulated to perform all required decoding, and reconstructing of the source signal. The proposed IKF was integrated into the receiver to estimate and optimize the received signals. Figure 4

shows a high level schematic of this model.

At the receiver, the corrupted signal goes through the IKF with UKF or EKF to perform the estimation steps on it before feeding it into the demodulator. Figure 5 shows schematic of the integrated IKF, which include the 2 KFs and a UKF as implemented in the receiver. It also includes the blocks to calculate the un-filtered phase and the UKF estimated phase, and their associated MSE.

6.2. Results

Simulation was run to compare the performance of the system with the integrated IKF versus the same system model without Kalman Filtering. Also, the performances of both the UKF and EKF were compared. Figure 6 shows the results when 200 samples of the received signal were plotted for non-filtered versus the IKF estimated signals, which consists of two KFs and one UKF. The non-noisy transmitted signal was used as a reference. Plots show clearly that IKF improves the signals significantly over the non-enhanced receiver. In the simulation, the SNR was set at value 10. This result shows the advantages of using simple algorithm like IKF to improve the results.

Figure 7 shows the corresponding Square Error (SE), of the un-processed (non-filtered) received signal versus the SE of the IKF estimated signal. These SE values were calculated in reference to the transmitted (non-noisy) signals for the same 200 samples as in Figure 6. Results have been consistent in showing that the implementation of IKF has improved the received signal significantly and consistently in enhancing the noncoherent modulation per-
