ABSTRACT

We present a new method for estimating missing values or correcting unreliable observed values of time dependent physical fields. This method, is based on Hidden Markov Models and Self-Organizing Maps, and is named PROFHMM_UNC. PROFHMM_UNC combines the knowledge of the physical process under study provided by an already known dynamic model and the truncated time series of observations of the phenomenon. In order to generate the states of the Hidden Markov Model, Self-Organizing Maps are used to discretize the available data. We make a modification to the Viterbi algorithm that forces the algorithm to take into account a priori information on the quality of the observed data when selecting the optimum reconstruction. The validity of PROFHMM_UNC was endorsed by performing a twin experiment with the outputs of the ocean biogeochemical NEMO-PISCES model.

Keywords:Multidimensional Time-Series Completion, Hidden Markov Models, Self-Organizing Maps

1. Introduction

Initialization is one of the main factors for the computation of accurate predictions in most of the numerical prediction models. Some of these models require a complete time-sequence in order to generate their predictions. Time series encountered in many research fields, however, often contain missing or unreliable data due to reasons such as malfunctioning sensors and human factors. The issue of completing such multidimensional time series has been addressed by many different statistical or machine learning methods, such as the Maximum likelihood algorithm [1] , expectation maximization algorithm [2] , K-Nearest Neighbor [3] , Varies Windows Similarity Measure [4] or Regional Gradient Guided Bootstrapping [5] . All these methods tend to reconstruct missing data that are subsequently used by the corresponding prediction models. Thus the reconstruction of the initial time-series is disconnected from the dynamic model.

Most dynamic numerical models that have been developed over the years can reproduce the available observations of the phenomena under study, with varying degrees of success. In Geophysical sciences there exists a large amount of data sets and dynamic models [6] related to different physical phenomena. The accuracy of such numerical models is measured by comparing their output values to these observations. After the initial implementation of the model, there are often further studies that use the available data sets and the first implementation of the model in order to modify its internal parameters and improve its accuracy. The most prominent field of study attempting to combine model and data for improving our knowledge of the phenomena under study is data assimilation [7] .

In this paper, we present a new method, which we will referred to as PROFHMM_UNC, for “PROFile reconstruction with HMM, taking into account UNCertainties” that combines the dynamic of the model and the available time series of observations in order to estimate the missing values or correct unreliable observed values. This is done by simplifying the dynamic model by transforming it into a multiple-state Hidden Markov Model (HMM). The reconstruction of the missing values and correction of the unreliable observations is done by applying a modified version of the Viterbi algorithm [8] which we introduce in this paper. This modification we introduce to the Viterbi algorithm uses a specific weighting function that modifies, during the optimum path selection process, the impact of the emission probability of an observation based on it’s a priori confidence. PROFHMM_UNC makes use of Self Organizing Maps to generate the hidden and observable states of the model as used in PROFHMM [9] , or SOS-HMM [10] .

In the following, we present the general methodology we used to achieve that task and give an example of its implementation by performing a twin experiment for reconstructing the oceanic sea-surface Chlorophyll-A distributions and sea-surface Temperature based on the NEMO-PISCES model [11] .

2. Methodology

The general theory behind the Hidden Markov Models is given in this section, followed by the introduction of our proposed modification to the Viterbi algorithm. This modification is used by the HMM for finding the most likely sequence of hidden states that results in a given sequence of observed events, when given an external indicator of the confidence in the data. We then briefly overview some of the advantages of discretizing multidimensional models into states through the use of self-organizing maps when trying to translate it into an HMM.

2.1. Hidden Markov Models

2.1.1. Modelisation

A first order Markov model is a stochastic model made of a set of possible states, and a transition probability matrix, noted. First order Markov models assume the first order Markovian property, meaning that each consecutive state of the model depends solely on its previous state. Therefore the transition probabilities of a temporal sequence of states, which are noted, are equal to . The transition probabilities are considered invariant with time. corresponds to a statistical learning of the dynamic processes governing the temporal transitions between these states.

Expanding this principle, a Hidden Markov Model (HMM) is a stochastic model with two sequences: one sequence of unobservable states, and one sequence of observations that have a statistical link with the unobservable states. We will henceforth refer to the unobservable states as hidden states, and symbolize them with. The hidden states are assumed to follow the first order Markovian property.

The observations are linked with the unobservable states through a probability density function or matrix. This density function, or the probability matrix elements, correspond to the existing links between the observations and the unobserved states, and are referred to as emission probabilities. The probability of having observed an observation, Obs, given that we are in the state i is called its emission probability, and is denoted. In the following we chose to restrict our presentation to a HMM with discrete observable states, denoted. A hidden state emits its observations according to an emission probability matrix, noted Em. The matrix elements connects the hidden states to the observable ones such as .

All the probabilities are determined during the training phase, by using an appropriate data set containing concurrent sequences of observed and known hidden states.

2.1.2. Reconstruction

After having determined the transitions and emissions probabilities, the Viterbi algorithm is then applied to find the most likely sequence of hidden states, given a sequence of concurrent observations. This is done by calculating, for each step of the observed sequence, the most likely sequence of states to end up at a given state, given the sequence of observations obtained up to that moment. The algorithm stocks these probabilities in a matrix, and the indexes of the states that generate these maximum probabilities for each state in another matrix. The algorithm then backpropagates to find the most likely sequence of indexes to have generated that sequence of observations.

The maximum probability to reach state j at time t is noted and can be formulated as:

, with corresponding to the observation at time t. We use the matrix, to store the index of most likely previous state of the Markov model to reach the state j at time t. This is primarily used when backpropagating through the algorithm in order to generate the most likely sequence of hidden states, which is noted. The probability of the sequence is noted P, and T correspond to the index of the final time-step. The complete algorithm is shown in Figure 1, and a graph representation of an HMM is shown in Figure 2.

2.2. Taking into Account Uncertainties

When applying HMMs it is generally assumed that the observation acquisition procedure and quality remain constant. However there are cases for which a combination of human errors and exterior parameters interfere and prevent the obtaining of sequences in which we have complete confidence in.

Given a Hidden Markov Model for which there exists a method for determining observation probabilities for which we have full confidence on the observation, we present a modification of the Viterbi algorithm which takes into account a change of confidence in a given observation.

To do so, we first introduce a confidence function, named. This function gives an external numerical evaluation of the quality of the observation. The function is scaled from 0 to 100, with 0 corresponding to a complete lack of confidence in the data (or a lack of data), and 100 corresponding to acquisition of a fully-trustworthy observation.

The confidence function is used, along with the by a weighting function, in order to introduce in the HMM the confidence we have in the observed data. The function needs to be monotonically decreasing for both and and takes values from 1 in the case of a non-trustable observation up to for a fully trustable observation. A typical form of which is parameterized by different values of can be seen in Figure 3. Other functions could be chosen depending on the a priori information we want to introduce.

The two functions are introduced in the Viterbi Algorithm when calculating the maximum probability to reach the state j at time t, by transforming it, from to . This corresponds to the transformation of the probability into a weighting term, which is no longer a probability.

Given a number of states with increasing a priori emission probabilities for the observation, their weighting terms will remain ordered in the same way for any non-null value of. Since all a priori emission probabilities are calculated from the same observation vector, they will also have the same confidence. We note that a decrease of the common value of increases all the weighting terms according to the curves representing the function family (Figure 3). As decreases, the weighting terms, converge towards 1, therefore progressively decreasing the impact of the a priori probabilities in the path selection of the Viterbi algorithm. A visual representation of one possible form of the functions family is shown in Figure 3.

When the confidence is null, , the function, and therefore , making the determination of the best path at the time t depend solely on the transition probabilities. Similarly, when the confidence is maximal, , the function and the determination of the best path at time t is done with the same process as with the unmodified Viterbi algorithm. The modification therefore can be considered a trade-off function between a regular Markov model and an HMM.

This method is general and can be applied in situations for which we have a high degree of confidence in the model and an exterior indicator of the quality of the observations.

2.3. Use of Self Organizing Maps with Hidden Markov Models

In order to build the HMM to model such a problem, it is necessary to discretize the dynamical model outputs into a discrete set of states. This can be a complicated task. A common method which is used in cases were the dynamical model can be described with few states, is to create independent states by clustering the available data [12] . A way to cluster the data is to reduce the dimension of the problem by using a Principal Component Analysis (PCA) [13] , and then make use of Learning Vector Quantization to generate states of the HMM [14] . However reducing of the dimension of the data through a PCA, would hinder the reconstruction of highly multidimensional vectors, and would not permit a fine discretization of the data, which is important in time-series completion. In our method we use Self-Organizing Topological Maps (SOM) which are clustering methods based on neural networks [15] . They provide a discretization of a learning dataset into a reduced number of subsets, called classes, which share some common statistical characteristics. Each class corresponds to an index. For each class, the hidden data attributed to it is represented by a referent vector, which approximates the mean value of the elements belonging to it. These referent vectors are used to label any other data of the same dimension with the index of the “nearest” referent vector. The indexes represent the states of the HMM and their referent vectors are used to generate sequences of indexes of states that serve to learn the emissions and transition probabilities.

The SOM training algorithm forces a topological ordering upon the map, and therefore any neighboring classes have referent vectors that are close in the Euclidean sense in the data space. This particularity is used by PROFHMM, and by extension by PROFHMM_UNC, to improve the emissions and transitions probabilities of the HMM. It permits the inclusion of a high number of states in the HMM modeling of a phenomenon for which we have relatively few concurrent hidden and observable vectors. The process of improving these probabilities is detailed in the Appendix.

3. Application

PROFHMM_UNC can be applied to real-world data for which we have a model that is consistent with the observed quantities. However, for the scope of this article we chose to perform a twin experiment with the outputs of the NEMO-PISCES model [10] , which allow us to present the general behavior and some quantified performances of the PROFHMM_UNC. Doing so we can control the behavior of PROFHMM_UNC for different situations: low or high confidence.

3.1. The Model

NEMO-PISCES is an ocean modeling framework which is composed of “engines” nested in an “environment”. The “engines” provide numerical solutions of ocean, sea-ice, tracers and biochemistry equations and their related physics. The “environment” consists of the preand post-processing tools, the interface to the other components of the Earth System, the user interface, the computer dependent functions and the documentation of the system. We obtained the output of this model by running the ORCA2_LIM_PISCES version of NEMO, which is a coupled ocean/sea-ice configuration based on the ORCA tripolar grid at 2˚ horizontal resolution forced with climatological forcing (winds, thermodynamic forcing) in conjunction with the PISCES biogeochemichal model [10] .

We extracted the five-day averaged outputs of this model at the grid points representing the BATS station (32 N - 64 W), shown in Figure 4. This station is one of the model calibration sites due to the existence of the Bermuda Atlantic Time Series (BATS) of the JGOFS campaign [12] . From the available data, we processed the values of the Sea Surface Temperature (SST), Sea Surface Chlorophyll-A (SCHL), Wind Speed (WS), the incident Shortwave Radiation (SR) and Sea Surface Elevation (SSH), averaged every five days. These averaged time steps are denoted t_NEMO. This gave us a complete data set of these five parameters for 1239 t_NEMO time-steps spanning from 1992 to 2008. We then generated a matrix containing the mean value of these parameters averaged for three consecutive t_NEMO time-steps. This average corresponds to the mean values of the parameters for a fifteen consecutive-days period, denoted t_HMM. The data set containing the values of the five “observable” parameters at the different t_HMM time-steps is noted Data_hid and is a five-dimensional matrix with 413 t_HMM time-steps.

In order to generate the observable situations and to simulate satellite data, we added to each geophysical parameter at the t_NEMO temporal resolution, a white noise following a Gaussian N (0, 0.35 * σ_param), where σ_param is the standard deviation of each parameter. The data was then once more averaged every 3 consecutive t_NEMO time steps, in order to reach the t_HMM temporal resolution. This generated the Data_obs matrix.

3.2. Statistical Learning and Weighting Function Configuration

The SOM map (denoted sMap_hid in the following) providing the hidden states of the HMM was trained with Data_hid. As described in Section 2.3, by classifying the Data_hid vectors, we generated a sequence of indexes, denoted SI_hid. These indexes correspond to the hidden states of the model at these consecutive t_HMM time-steps.

The SOM map (denoted sMap_obs in the following) providing the observable states of the HMM was trained with Data_obs. Since the generation of Data_obs included the calculation of the mean value at the t_NEMO temporal resolution, the white noises added to the signal is smoothed. Data_obs is a five-dimensional data set (containing SCHL, SST, SSH, WS, SR) with 413 rows. The sequence of indexes of the observable data, SI_obs coincides temporally with SI_hid, and was generated by classifying the Data_obs vectors.

The generation of the hidden and observable states was done by using the two SOMs. Both sMap_hid and sMap_obs contain 108 neurons that represent, respectively, the hidden and observable states of the HMM, distributed on an array formed of 12 by 9 lattices. They were generated using Data_hid and Data_obs from 1992 to 2005, each data set corresponding to 340 t_HMM time steps; the sequence of observations from the year 2006, corresponding to 24 t_HMM time steps, were used as a validation set, and the years 2007 and 2008, corresponding to a sequence of 49 t_HMM time steps, were used to test the performance of the method.

The size of the maps were set by iteratively increasing the number of states of each map, selecting the dimensions that had the smallest root mean square (RMS) errors between the actual data of the validation year 2006 and its reconstruction by PROFHMM.

In Figure 5(a) we present, projected on the first plane given by the PCA of Data_hid, the spatial distribution of the referent vectors of the hidden states as red circles, while the blue crosses correspond to the data vectors from Data_hid. Similarly, in Figure 5(b) we present, projected on the first plane of the PCA of Data_obs, the spatial distribution of the referent vectors of the hidden states as red circles, while the blue crosses correspond to the data vectors from Data_obs. The first plane of the PCA of the hidden data set corresponds to 69.3% of its variance, while the first plane of the PCA of the observable data set corresponds to 68.2% of its variance. Both hidden and observable states are well distributed over their respective data set. Therefore we can make the assumption that the selected states represent accurately the variance of the observed phenomenon. It is important to note that this is just a projection of the data on the first plane and that we did not reduce the dimension of our vectors by applying this PCA.

The SOM maps were trained with the algorithms provided by the matlab som toolbox [15] , specifically the functions som_make, som_batchtrain, som_bmus in order to train our maps and classify our data.

The SOM maps were used to classify the datasets and generate two sequences of state indexes, SI_obs and SI_hid. These sequences were subsequently used to train the Hidden Markov Model according to the procedure presented in Section 2, and to estimate the HMM parameters.

The weighting function was set to whose form can be seen in Figure 3. The determination of the form of this function and the specific values for the exponential, was a modeling choice made to force a slight degradation of for high, while greatly increasing them for very low ones.

We made the assumption that, due to exterior factors such as heavy cloud coverage or satellite instrument malfunction, only during some (or none) of these time-steps there were observations available. The confidence function was therefore defined as the percentage of available time-steps used to generate the observation. The flowchart of PROFHMM_UNC for the twin experiment is shown in Figure 6.

3.3. Performances

To test the performances of the model, we classified the hidden and observable data from the years 2007 and 2008 according to their respective sMaps. However, we simulated a perturbed sequence of data for which we introduced exterior indicators of confidence: for twelve consecutive t_HMM time steps we considered that the observable data was not given from the mean of three consecutive t_NEMO time steps, but by the value of only one of these. Doing so we increased the noise level of those specific data points. Therefore, an empiric way to set the confidence value at approximately a third of the maximum confidence, , since we sampled the data at the rate of one out of the three consecutive time-steps.

The twelve consecutive time-steps data shown in Figure 7, correspond to a period spanning from October 2007 to March 2008. We focused on the reconstruction of the Chlorophyll-A, in Figure 7(a) and the temperature, in Figure 7(b). The curves in this figure correspond to the reconstructions: in red for a complete confidence in the observations and in green for the aforementioned. The real model values are in blue. We can see that, by applying the PROFHMM_UNC, we increased our trust in the transitions probabilities of the HMM and better fitted the curve of the real data.

After presenting these results, we progressively varied the value of by increments of 5, and plotted the resulting curves of CHL and SST for the 7 t_NEMO time step period which had their sampling modified. As seen in Figure 8, we only obtain 5 different curves when performing this experience. In orange, we can see that if we give zero to small confidence in the data, we obtain a curve that almost does not take into account the observations and chooses the hidden states based on transitions only. The reconstruction therefore is far away from reality. In green we have the result obtained when we have a small, but not null confidence in the observations, this curve is closer to the NEMO values. In black, we have the values obtained with a higher confidence in the data. The black curve follows the NEMO-PISCES values quite well; is hidden by the green curve up to the fifth time step, then approximates the real data slightly better. Finally when we completely trust the data, the model takes too much into account the modified observed data, increasing therefore the error of the reconstruction.

It is interesting to note that there are only 5 curves obtained when varying the values of. This is due to the way the Viterbi Algorithm functions, whose principle is to select the optimum path: slight changes in the values of confidence will create slight modifications, which are often not enough to overcome a threshold value needed to change the index of the selected state, therefore generating the same path. The choice of the form of family of functions controls the speed of the decrease of the impact of the a priori emissions probabilities on the selection of the optimum path by the Viterbi Algorithm. This, in turn also changes the length and placement of the intervals of values that present the same reconstruction.

Figure 8 also raises another important point on the determination of the function. In the experiment above, we initially considered an empirical value of 35, trying to approximate the fact that we only sampled the data at the rate of one out of the 3 t_NEMO time steps. This was equivalent to assuming that they were independently selected using a simple probability distribution. However, as seen in Figure 8, the results obtained in the interval better fitted the data. This happens because the t_NEMO time step sampling is strongly correlated with the two ignored ones, and its associated data value contains a significant percentage of the total information we would have obtained by sampling all of the time steps. Therefore, it is important to perform a preliminary study to determine the confidence function that best fits the problem. This is especially true in the cases for which PROFHMM_UNC could be applied, since spatial and temporal sampling at different resolutions is often encountered in different fields of study, such as geophysical problems related to satellite information.

In order to present a quantifiable measure of the improvement obtained by applying PROFHMM_UNC, we performed a dedicated test by generating 10.000 different Data_obs. This was done while varying the placement of the consecutive 7 t_HHM time steps period of low confidence throughout the 2 testing year period. The Data_obs matrices were generated by adding a, significantly stronger, white noise, that follows N (0, 1.5 * σ_param) distribution, to the Data_hid. We then calculated, for the years 2007-2008 the RMS errors between the reconstructed and NEMO outputs of the sea surface chlorophyll-a and sea surface temperature for each confidence interval. The results are shown in Table1

The values obtained indicate an improvement when taking into account the uncertainty of the observations. Once more we can see that, by applying the results are globally improved. This

highlights the importance of performing a preliminary study to determine the appropriate confidence function for each phenomenon.

There exist variations of the Viterbi algorithm such as Lazy Viterbi [16] and the Soft Output Viterbi [17] [18] . We limited ourselves to the Viterbi Algorithm, yet the modification could easily be applied to those approaches.

4. Conclusions

In this paper we have presented PROFHMM_UNC, a new methodology that combines a dynamic model and observations in order to constrain the outputs of a dynamic model to better fit the observations, while respecting the dynamic processes of the model. This was used to complete time-sequences with missing data, and to correct observations for which we have an external indicator of unreliability. The improvements obtained by using the method were illustrated through a twin experiment. The results of this experiment highlight the importance of performing a preliminary study to determine a case-appropriate confidence function. PROFHMM_UNC is very general and could be applied to model a system which is not described numerically, by learning the dynamic processes using a large amount of sequences of observations.

Going forward we might intend to apply this methodology for generating realistically complete time series of states, based on real satellite observations, to further be used by PROFHMM in order to retrieve 3D fields of parameters based on discrete observations generated by PROFHMM_UNC.

Acknowledgements

The research presented in this paper was financed by Centre National de l’Etude Spatial (CNES, French national center of spatial studies), and the Delegation Gouvernemantale pour l’Armement (DGA, French Military Research Delegation), which we wish to thank for their support. We wish to also thank Cyril Moulin and Laurent Bopp from LSCE for their help with NEMO-PISCES and Michel Crepon for his input on the method.

References

Appendix

Advantages of Using Self-Organizing Maps for the Determination of HMM States

Self-Organizing Topological Maps (SOM) which are clustering methods based on neural networks. They provide a discretization of a learning dataset into a reduced number of subsets, called classes, which share some common statistical characteristics. Each class is represented by a referent vector, which approaches the mean value of the elements belonging to it, since the training algorithm can be forced to perform like the K-means algorithm at the final stages of its training.

The topological aspect of the maps can be justified by considering the Map as an undirected graph on a twodimensional lattice whose vertices are the classes. This graph structure permits the definition of a discrete distance, noted d, between two classes, defined as the length of the shortest path between them on the map.

Any vector that is of the same dimensions and nature as the data used to generate the topological map, can be classified by assigning it to the class whose referent it resembles most. Therefore a sequence of data vectors can be classified in order to generate a sequence of indexes that correspond to the indexes of the classes to which they were assigned.

In our method, we trained two SOMs, the first containing the observations, called sMap_obs and the second containing the hidden states, called sMap_hid. The hidden states correspond to the discretization of the numerical dynamic model.

The classes of sMap_obs and sMap_hid correspond respectively to the discretization of the observation vectors into a set amount of observable states, , and to the hidden states of the HMM,.

The topological aspect of the SOMs is useful in overcoming the usual lack of sufficient data in estimating the transition and emission probabilities of the HMM. After an initial estimation of the probabilities over each available training sequence, noted seq, these transitions, Tr_seq, and emissions Em_seq, can be combined and adjusted by taking into account the neighboring properties of the topological maps.

This is done by considering the neighborhood matrices NM_obs and NM_hid, of dimensions and respectively, where

, (1)

with being the discrete distance on the respective maps.

The final Em and Tr matrices we used, noted Em_final and Tr_final, were computed by applying for and for:

, (2)

Which was normalized to become wherefor

, (3)

which is normalized to become where.

The term corresponds to a weighting constant that prevents the actual measured probabilities from being overshadowed by their neighborhood values. Its value is determined by an iterative optimization process on an independent test data set. In the case of the application (Section 3.2) its value is taken to be equal to 9. The impact of neighboring states on the probabilities has been schematized in Figure A1.

It is important to retain that in order to apply PROFHMM_UNC, we require a training data set of concurrent hidden and observable states sequences. This, unlike more complicated cases of HMMs (such as voice recognition software), permits for an estimation of the initial emissions and transition probabilities through the use of a counting algorithm such as hmmestimate of the matlabstat_toolbox.
