Existence of Solutions of Three-Dimensional Fractional Differential Systems

DOI: 10.4236/am.2017.82016    1,051 Downloads   1,421 Views   Citations
Author(s)    Leave a comment

In this article, we consider the three-dimensional fractional differential system of the form together with the Neumann boundary conditions, where are the standard Caputo fractional derivatives, . A new result on the existence of solutions for a class of fractional differential system is obtained by using Mawhin’s coincidence degree theory. Suitable examples are given to illustrate the main results.

${u}^{\prime }\left(0\right)={u}^{\prime }\left(1\right)=0,\text{}{v}^{\prime }\left(0\right)={v}^{\prime }\left(1\right)=0,\text{}{w}^{\prime }\left(0\right)={w}^{\prime }\left(1\right)=0,$

where ${D}_{{0}^{+}}^{\alpha },\text{}{D}_{{0}^{+}}^{\beta },\text{}{D}_{{0}^{+}}^{\gamma }$ are the standard Caputo fractional derivatives, $1<\alpha ,\beta ,\gamma \le 2$ . A new result on the existence of solutions for a class of fractional differential system is obtained by using Mawhin’s coincidence degree theory. Suitable examples are given to illustrate the main results.

Keywords: 1. Introduction

Fractional calculus is a very effective tool in the modeling of many phenomena like control of dynamical systems, porous media, electro chemistry, viscoelasticity, electromagnetic and so on. The fractional theory and its applications are mentioned by many papers and monographs, we refer  -  . For nonlinear fractional boundary value problem, many fixed point theorems were applied to investigate the existence of solutions as in references     . On the other hand, there is another effective approach, Mawhin’s coincidence theory, which proves to be very useful for determining the existence of solutions for fractional order differential equations. In recent years, boundary value problems for fractional differential equations at resonance have been studied in many papers (see  -  ). The main motivation for investigating the fractional boundary value problem arises from fractional advection-dispersion equation.

Hu et al.  investigated the two-point boundary value problem for fractional differential equations of the following form

$\begin{array}{l}{D}_{{0}^{+}}^{\alpha }x\left(t\right)=f\left(t,x\left(t\right),{x}^{\prime }\left(t\right)\right),\text{}t\in \left[0,1\right],\\ x\left(0\right)=0,{x}^{\prime }\left(0\right)={x}^{\prime }\left(1\right),\end{array}$

where ${D}_{{0}^{+}}^{\alpha }$ is the Caputo fractional differential operator, $1<\alpha \le 2$ , and $f:\left[0,1\right]×{R}^{2}\to R$ is continuous.

In  , Hu et al. extended the above boundary value problem to the existence of solutions for the following coupled system of fractional differential equations of the form

$\begin{array}{l}{D}_{{0}^{+}}^{\alpha }u\left(t\right)=f\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right),\text{}t\in \left(0,1\right),\\ {D}_{{0}^{+}}^{\beta }v\left(t\right)=g\left(t,u\left(t\right),{u}^{\prime }\left(t\right)\right),\text{}t\in \left(0,1\right),\\ u\left(0\right)=v\left(0\right)=0,\text{}{u}^{\prime }\left(0\right)={u}^{\prime }\left(1\right),\text{}{v}^{\prime }\left(0\right)={v}^{\prime }\left(1\right).\end{array}$

where ${D}_{{0}^{+}}^{\alpha },\text{}{D}_{{0}^{+}}^{\beta }$ are the Caputo fractional derivatives, $1<\alpha \le 2,$ $1<\beta \le 2$ , and $f,g:\left[0,1\right]×{R}^{2}\to R$ is continuous.

It seems that there has been no work done on the boundary value problem of system involving three nonlinear fractional differential equations. Motivated by the above observation, we investigate the following three-dimensional fractional differential system of the form

$\begin{array}{l}{D}_{{0}^{+}}^{\alpha }u\left(t\right)={f}_{1}\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right),\text{}t\in \left(0,1\right),\\ {D}_{{0}^{+}}^{\beta }v\left(t\right)={f}_{2}\left(t,w\left(t\right),{w}^{\prime }\left(t\right)\right),\text{}t\in \left(0,1\right),\\ {D}_{{0}^{+}}^{\gamma }w\left(t\right)={f}_{3}\left(t,u\left(t\right),{u}^{\prime }\left(t\right)\right),\text{}t\in \left(0,1\right),\end{array}$ (1)

together with the Neumann boundary conditions,

${u}^{\prime }\left(0\right)={u}^{\prime }\left(1\right)=0,\text{}{v}^{\prime }\left(0\right)={v}^{\prime }\left(1\right)=0,\text{}{w}^{\prime }\left(0\right)={w}^{\prime }\left(1\right)=0,$

where ${D}_{{0}^{+}}^{\alpha },\text{}{D}_{{0}^{+}}^{\beta },\text{}{D}_{{0}^{+}}^{\gamma }$ are the standard Caputo fractional derivatives, $1<\alpha ,\beta ,\gamma$ Math_19#, and ${f}_{1},{f}_{2},{f}_{3}:\left[0,1\right]×R×R\to R$ is continuous.

The main goal of this paper is to establish some new criteria for the existence of solutions of (1). The method is based on Mawhin’s coincidence degree theory. The results in this paper are generalized of the existing ones.

2. Preliminaries

In this section, we give the definitions of fractional derivatives and integrals and some notations which are useful throughout this paper. There are several kinds of definitions of fractional derivatives and integrals. In this paper, we use the Riemann-Liouville left sided definition on the half-axis ${R}_{+}$ and the Caputo fractional derivative.

Let X and Y be real Banach spaces and let $L:\text{dom}L\subset X\to Y$ be a Fred- holm operator with index zero if $\mathrm{dim}\text{Ker}L=\text{codim}\mathrm{Im}L<\infty$ and ImL is closed in Y and there exist continuous projectors $P:X\to X,Q:Y\to Y$ such that

$\mathrm{Im}P=\text{Ker}L,\text{Ker}Q=\mathrm{Im}L,\text{}X=\text{Ker}L\oplus \text{Ker}P,\text{}Y=\mathrm{Im}L\oplus \mathrm{Im}Q.$

It follows that

${L|}_{\text{dom}L\cap \text{Ker}P}:\mathrm{dom}L\cap \text{Ker}P\to \mathrm{Im}L$

is invertible. Here ${K}_{P}$ denotes the inverse of ${L|}_{\text{dom}L\cap \text{Ker}P}$ .

If $\Omega$ is an open bounded subset of X, and $\text{dom}L\cap \stackrel{¯}{\Omega }\ne \varphi$ , then the map $N:X\to Y$ will be called L-compact on $\stackrel{¯}{\Omega }$ , if $QN\left(\stackrel{¯}{\Omega }\right)$ is bounded and ${K}_{P}\left(I-Q\right)N:\stackrel{¯}{\Omega }\to X$ is compact, where I is the identity operator.

Lemma 1.  Let $L:\text{dom}L\subset X\to Y$ be a Fredholm operator with index zero and $N:X\to Y$ be L-compact on $\stackrel{¯}{\Omega }$ . Assume that the following condi- tions are satisfied.

1. $Lx\ne \lambda Nx$ for every $\left(x,\lambda \right)\in \left[\left(\text{dom}L\\text{Ker}L\right)\cap \partial \Omega \right]×\left(0,1\right)$ ;

2. $Nx\notin \mathrm{Im}L$ for every $x\in \text{Ker}L\cap \partial \Omega$ ;

3. $\mathrm{deg}\left({QN|}_{\text{Ker}L},\text{Ker}L\cap \Omega ,0\right)\ne 0$ , where $Q:Y\to Y$ is a projection such that $\mathrm{Im}L=\text{Ker}Q$ .

Then the operator equation $Lx=Nx$ has at least one solution in $\text{dom}L\cap \stackrel{¯}{\Omega }$ .

Definition 1.  The Riemann-Liouville fractional integral of order $\alpha >0$ of a function $y:{R}_{+}\to R$ on the half-axis ${R}_{+}$ is given by

$\left({I}_{{0}^{+}}^{\alpha }y\right)\left(t\right):=\frac{1}{\Gamma \left(\alpha \right)}{\int }_{0}^{t}{\left(t-v\right)}^{\alpha -1}y\left(v\right)\text{d}v\text{ }\text{for}\text{ }\text{ }t>0$

provided the right hand side is pointwise defined on ${R}_{+}.$

Definition 2.  Assume that $x\left(t\right)$ is $\left(n-1\right)$ -times absolutely continuous function, the Caputo fractional derivative of order $\alpha >0$ of x is given by

$\left({D}_{{0}^{+}}^{\alpha }x\right)\left(t\right):={I}_{{0}^{+}}^{n-\alpha }\frac{{\text{d}}^{n}x\left(t\right)}{\text{d}{t}^{n}}=\frac{1}{\Gamma \left(n-\alpha \right)}{\int }_{0}^{t}{\left(t-v\right)}^{n-\alpha -1}{x}^{\left(n\right)}\left(v\right)\text{d}v\text{ }\text{ }\text{for}\text{ }\text{ }t>0$

where n is the smallest integer greater than or equal to $\alpha$ , provided that the right side integral is pointwise defined on $\left(0,+\infty \right)$ .

Lemma 2.  Let $\alpha >0$ and $n=-\left[-\alpha \right]$ . If ${x}^{\left(n-1\right)}\in AC\left[0,1\right]$ , then

${I}_{{0}^{+}}^{\alpha }{D}_{{0}^{+}}^{\alpha }x\left(t\right):=x\left(t\right)+{c}_{0}+{c}_{1}t+{c}_{2}{t}^{2}+\cdots +{c}_{n-1}{t}^{n-1}$

where ${c}_{i}=-\frac{{x}^{\left(i\right)}\left(0\right)}{i!}\in R,\text{}i=0,1,2,\cdots ,n-1$ , here n is the smallest integer greater

than or equal to $\alpha$ .

In this paper, let us take $X={C}^{1}\left[0,1\right]$ with the norm ${‖x‖}_{X}=\mathrm{max}\left\{{‖x‖}_{\infty },{‖{x}^{\prime }‖}_{\infty }\right\}$ and $Y=C\left[0,1\right]$ with the norm ${‖y‖}_{Y}={‖y‖}_{\infty }$ , where ${‖x‖}_{\infty }={\mathrm{max}}_{t\in \left[0,1\right]}|x\left(t\right)|$ . Then we denote $\stackrel{¯}{X}=X×X×X$ with the norm ${‖\left(u,v,w\right)‖}_{\stackrel{¯}{X}}=\mathrm{max}\left\{{‖u‖}_{X},{‖v‖}_{X},{‖w‖}_{X}\right\}$ and $\stackrel{¯}{Y}=Y×Y×Y$ with the norm ${‖\left(x,y,z\right)‖}_{\stackrel{¯}{Y}}=\mathrm{max}\left\{{‖x‖}_{Y},{‖y‖}_{Y},{‖z‖}_{Y}\right\}$ . Clearly, both $\stackrel{¯}{X}$ and $\stackrel{¯}{Y}$ are Banach spaces.

Define the operators ${L}_{i}:\text{dom}L\subset X\to Y,\text{}\left(i=1,2,3\right)$ by

${L}_{1}u={D}_{{0}^{+}}^{\alpha }u,\text{}{L}_{2}v={D}_{{0}^{+}}^{\beta }v\text{and}{L}_{3}w={D}_{{0}^{+}}^{\gamma }w,$

where

$\text{dom}{L}_{1}=\left\{u\in X|{D}_{{0}^{+}}^{\alpha }u\left(t\right)\in Y,{u}^{\prime }\left(0\right)={u}^{\prime }\left(1\right)=0\right\},$

$\text{dom}{L}_{2}=\left\{v\in X|{D}_{{0}^{+}}^{\beta }v\left(t\right)\in Y,{v}^{\prime }\left(0\right)={v}^{\prime }\left(1\right)=0\right\},$

and

$\text{dom}{L}_{3}=\left\{w\in X|{D}_{{0}^{+}}^{\gamma }w\left(t\right)\in Y,{w}^{\prime }\left(0\right)={w}^{\prime }\left(1\right)=0\right\}.$

Define the operator $L:\text{dom}L\subset \stackrel{¯}{X}\to \stackrel{¯}{Y}$ by

$L\left(u,v,w\right)=\left({L}_{1}u,{L}_{2}v,{L}_{3}w\right),$ (2)

where $\text{dom}L=\left\{\left(u,v,w\right)\in \stackrel{¯}{X}|u\in \text{dom}{L}_{1},v\in \text{dom}{L}_{2},w\in \text{dom}{L}_{3}\right\}.$

Let the Nemytski operator $N:\stackrel{¯}{X}\to \stackrel{¯}{Y}$ be defined as

$N\left(u,v,w\right)=\left({N}_{1}v,{N}_{2}w,{N}_{3}u\right),$

where ${N}_{1}:X\to Y$ is defined by

${N}_{1}v\left(t\right)={f}_{1}\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right),$

${N}_{2}:X\to Y$ is defined by

${N}_{2}w\left(t\right)={f}_{2}\left(t,w\left(t\right),{w}^{\prime }\left(t\right)\right),$

and ${N}_{3}:X\to Y$ is defined by

${N}_{3}u\left(t\right)={f}_{3}\left(t,u\left(t\right),{u}^{\prime }\left(t\right)\right).$

Then Neumann boundary value problem (1) is equivalent to the operator equation

$L\left(u,v,w\right)=N\left(u,v,w\right),\text{}\left(u,v,w\right)\in \text{dom}L.$

3. Main Results

In this section, we begin with the following theorem on existence of solutions for

Neumann boundary value problem (1).

Theorem 1. Let ${f}_{1},{f}_{2},{f}_{3}:\left[0,1\right]×R×R\to R$ be continuous. Assume that

(H1) there exist nonnegative functions ${a}_{i},{b}_{i},{c}_{i}\in C\left[0,1\right],\text{}\left(i=1,2,3\right)$ with

$\frac{\Gamma \left(\alpha \right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)-\left({B}_{1}+{C}_{1}\right)\left({B}_{2}+{C}_{2}\right)\left({B}_{3}+{C}_{3}\right)}{\Gamma \left(\alpha \right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)}>0$

such that for all $\left(u,v\right)\in {R}^{2},\text{}t\in \left[0,1\right],$

$|{f}_{i}\left(t,u,v\right)|\le {a}_{i}\left(t\right)+{b}_{i}\left(t\right)|u|+{c}_{i}\left(t\right)|v|\text{ }\text{for}\text{ }i=1,2,3,$

where ${A}_{i}={‖{a}_{i}‖}_{\infty },{B}_{i}={‖{b}_{i}‖}_{\infty },{C}_{i}={‖{c}_{i}‖}_{\infty },\text{}\left(i=1,2,3\right)$ ;

(H2) there exists a constant $M>0$ such that for all $t\in \left[0,1\right],\text{}|u|>M,\text{}v\in R$ either

$u{f}_{1}\left(t,u,v\right)>0,\text{}u{f}_{2}\left(t,u,v\right)>0,\text{}u{f}_{3}\left(t,u,v\right)>0$

or

$u{f}_{1}\left(t,u,v\right)<0,\text{}u{f}_{2}\left(t,u,v\right)<0,\text{}u{f}_{3}\left(t,u,v\right)<0;$

(H3) there exists a constant ${M}^{*}>0$ such that for every ${m}_{1},{m}_{2},{m}_{3}\in R$ satisfying $\mathrm{min}\left\{{m}_{1},{m}_{2},{m}_{3}\right\}>{M}^{*}$ either

${m}_{1}{N}_{1}\left({m}_{2}\right)>0,\text{}{m}_{2}{N}_{2}\left({m}_{3}\right)>0,\text{}{m}_{3}{N}_{3}\left({m}_{1}\right)>0$

or

${m}_{1}{N}_{1}\left({m}_{2}\right)<0,\text{}{m}_{2}{N}_{2}\left({m}_{3}\right)<0,\text{}{m}_{3}{N}_{3}\left({m}_{1}\right)<0.$

Then Neumann boundary value problem (1) has at least one solution.

Lemma 3. Let L be defined by (2). Then

$\begin{array}{c}\text{Ker}L=\left(\text{Ker}{L}_{1},\text{Ker}{L}_{2},\text{Ker}{L}_{3}\right)\\ =\left\{\left(u,v,w\right)\in \stackrel{¯}{X}|\left(u,v,w\right)=\left(u\left(0\right),v\left(0\right),w\left(0\right)\right)\right\},\end{array}$ (3)

and

$\begin{array}{c}\mathrm{Im}L=\left(\mathrm{Im}{L}_{1},\mathrm{Im}{L}_{2},\mathrm{Im}{L}_{3}\right)\\ =\left\{\left(x,y,z\right)\in \stackrel{¯}{Y}|{\int }_{0}^{1}{\left(1-s\right)}^{\alpha -2}x\left(s\right)\text{d}s\\ ={\int }_{0}^{1}{\left(1-s\right)}^{\beta -2}y\left(s\right)\text{d}s={\int }_{0}^{1}{\left(1-s\right)}^{\gamma -2}z\left(s\right)\text{d}s=0\right\}.\end{array}$ (4)

Proof. By Lemma 2, ${L}_{1}u={D}_{{0}^{+}}^{\alpha }u\left(t\right)=0$ has the solution

$u\left(t\right)=u\left(0\right)+{u}^{\prime }\left(0\right)t.$

From the boundary conditions, we have

$\text{Ker}{L}_{1}=\left\{u\in X|u=u\left(0\right)\right\}.$

For $x\in \mathrm{Im}{L}_{1}$ , there exists $u\in \text{dom}{L}_{1}$ such that $x={L}_{1}u\in Y$ . By using the Lemma 2, we get

$u\left(t\right)=\frac{1}{\Gamma \left(\alpha \right)}{\int }_{0}^{t}{\left(t-s\right)}^{\alpha -1}x\left(s\right)\text{d}s+u\left(0\right)+{u}^{\prime }\left(0\right)t.$

Then, we have

${u}^{\prime }\left(t\right)=\frac{1}{\Gamma \left(\alpha -1\right)}{\int }_{0}^{t}{\left(t-s\right)}^{\alpha -2}x\left(s\right)\text{d}s+{u}^{\prime }\left(0\right).$

By the boundary value conditions of (1), we can get that x satisfies

${\int }_{0}^{1}{\left(1-s\right)}^{\alpha -2}x\left(s\right)\text{d}s=0.$

On the other hand, suppose $x\in Y$ and satisfies ${\int }_{0}^{1}{\left(1-s\right)}^{\alpha -2}x\left(s\right)\text{d}s=0.$ Let $u\left(t\right)={I}_{{0}^{+}}^{\alpha }x\left(t\right),$ then $u\in \text{dom}{L}_{1}$ and ${D}_{{0}^{+}}^{\alpha }u\left(t\right)=x\left(t\right)$ . Hence, $x\in \mathrm{Im}{L}_{1}$ . Then we get

$\mathrm{Im}{L}_{1}=\left\{x\in Y|{\int }_{0}^{1}{\left(1-s\right)}^{\alpha -2}x\left(s\right)\text{d}s=0\right\}.$

Similarly, we have

$\text{Ker}{L}_{2}=\left\{v\in X|v=v\left(0\right)\right\},\text{}\mathrm{Im}{L}_{2}=\left\{y\in Y|{\int }_{0}^{1}{\left(1-s\right)}^{\beta -2}y\left(s\right)\text{d}s=0\right\},$

and

$\text{Ker}{L}_{3}=\left\{w\in X|w=w\left(0\right)\right\},\text{}\mathrm{Im}{L}_{3}=\left\{z\in Y|{\int }_{0}^{1}{\left(1-s\right)}^{\gamma -2}z\left(s\right)\text{d}s=0\right\}.$

$\square$

Lemma 4. Let L be defined by (2). Then L is a Fredholm operator of index zero, $P:\stackrel{¯}{X}\to \stackrel{¯}{X}$ and $Q:\stackrel{¯}{Y}\to \stackrel{¯}{Y}$ are the linear continuous projector opera- tors can be defined as

$P\left(u,v,w\right)=\left({P}_{1}u,{P}_{2}v,{P}_{3}w\right)=\left(u\left(0\right),v\left(0\right),w\left(0\right)\right),$

$\begin{array}{c}Q\left(x,y,z\right)=\left({Q}_{1}x,{Q}_{2}y,{Q}_{3}z\right)\\ =\left(\left(\alpha -1\right){\int }_{0}^{1}{\left(1-s\right)}^{\alpha -2}x\left(s\right)\text{d}s,\\ \text{}\left(\beta -1\right){\int }_{0}^{1}{\left(1-s\right)}^{\beta -2}y\left(s\right)\text{d}s,\left(\gamma -1\right){\int }_{0}^{1}{\left(1-s\right)}^{\gamma -2}z\left(s\right)\text{d}s\right).\end{array}$

Further more, the operator ${K}_{P}:\mathrm{Im}L\to \text{dom}L\cap \text{Ker}P$ can be written by

${K}_{P}\left(x,y,z\right)=\left({I}_{{0}^{+}}^{\alpha }x\left(t\right),{I}_{{0}^{+}}^{\beta }y\left(t\right),{I}_{{0}^{+}}^{\gamma }z\left(t\right)\right).$

Proof. Clearly, $\mathrm{Im}P=\text{Ker}L$ and ${P}^{2}\left(u,v,w\right)=P\left(u,v,w\right)$ . It follows that $\left(u,v,w\right)=\left(\left(u,v,w\right)-P\left(u,v,w\right)\right)+P\left(u,v,w\right)$ , we have $\stackrel{¯}{X}=\text{Ker}P+\text{Ker}L$ . By using simple calculation, we get that $\text{Ker}L\cap \text{Ker}P=\left\{\left(0,0,0\right)\right\}$ . Then we have

$\stackrel{¯}{X}=\text{Ker}P\oplus \text{Ker}L.$

For $\left(x,y,z\right)\in \stackrel{¯}{Y}$ , we have

${Q}^{2}\left(x,y,z\right)=Q\left({Q}_{1}x,{Q}_{2}y,{Q}_{3}z\right)=\left({Q}_{1}^{2}x,{Q}_{2}^{2}y,{Q}_{3}^{2}z\right)$

By the definition of ${Q}_{1}$ , we get

${Q}_{1}^{2}x={Q}_{1}x\cdot \left(\alpha -1\right){\int }_{0}^{1}{\left(1-s\right)}^{\alpha -2}x\left(s\right)\text{d}s={Q}_{1}x.$

Similarly, we can show that ${Q}_{2}^{2}y={Q}_{2}y$ and ${Q}_{3}^{2}z={Q}_{3}z$ . Thus, we can get ${Q}^{2}\left(x,y,z\right)=Q\left(x,y,z\right)$ .

Let

$\left(x,y,z\right)=\left(\left(x,y,z\right)-Q\left(x,y,z\right)\right)+Q\left(x,y,z\right)$ ,

where $\left(x,y,z\right)-Q\left(x,y,z\right)\in \text{Ker}Q,$ $Q\left(x,y,z\right)\in \mathrm{Im}Q$ . It follows that $\text{Ker}Q=\mathrm{Im}L$ and ${Q}^{2}\left(x,y,z\right)=Q\left(x,y,z\right)$ , we get $\mathrm{Im}Q\cap \mathrm{Im}L=\left\{\left(0,0,0\right)\right\}$ . It is clear that

$\stackrel{¯}{Y}=\mathrm{Im}L\oplus \mathrm{Im}Q.$

Thus

$\mathrm{dim}\text{Ker}L=\mathrm{dim}\mathrm{Im}Q=\text{codim}\mathrm{Im}L.$

Hence L is a Fredholm operator of index zero.

From the definitions of P and ${K}_{P}$ , we will prove that ${K}_{P}$ is the inverse of ${L|}_{\text{dom}L\cap \text{Ker}P}$ . Infact, for $\left(x,y,z\right)\in \mathrm{Im}L$ , we have

$L{K}_{P}\left(x,y,z\right)=\left({D}_{{0}^{+}}^{\alpha }\left({I}_{{0}^{+}}^{\alpha }x\right),{D}_{{0}^{+}}^{\beta }\left({I}_{{0}^{+}}^{\beta }y\right),{D}_{{0}^{+}}^{\gamma }\left({I}_{{0}^{+}}^{\gamma }z\right)\right)=\left(x,y,z\right).$ (5)

Moreover, for $\left(u,v,w\right)\in \text{dom}L\cap \text{Ker}P$ , we have $u\left(0\right)=v\left(0\right)=w\left(0\right)=0$ and

$\begin{array}{c}{K}_{P}L\left(u,v,w\right)=\left({I}_{{0}^{+}}^{\alpha }\left({D}_{{0}^{+}}^{\alpha }u\left(t\right)\right),{I}_{{0}^{+}}^{\beta }\left({D}_{{0}^{+}}^{\beta }v\left(t\right)\right),{I}_{{0}^{+}}^{\gamma }\left({D}_{{0}^{+}}^{\gamma }w\left(t\right)\right)\right)\\ =\left(u\left(t\right)-u\left(0\right)-{u}^{\prime }\left(0\right)t,v\left(t\right)-v\left(0\right)-{v}^{\prime }\left(0\right)t,w\left(t\right)-w\left(0\right)-{w}^{\prime }\left(0\right)t\right),\end{array}$

which together with the boundary condition ${u}^{\prime }\left(0\right)={v}^{\prime }\left(0\right)={w}^{\prime }\left(0\right)=0$ yields that

${K}_{P}L\left(u,v,w\right)=\left(u,v,w\right).$ (6)

From (5) and (6), we get ${K}_{P}={\left({L|}_{\text{dom}L\cap \text{Ker}P}\right)}^{-1}$ . $\square$

Lemma 5. Assume $\Omega \subset \stackrel{¯}{X}$ is an open bounded subset such that $\text{dom}L\cap \stackrel{¯}{\Omega }\ne \varphi$ , then N is L-compact on $\stackrel{¯}{\Omega }$ .

Proof. By the continuity of f1, f2 and f3, we can get $QN\left(\stackrel{¯}{\Omega }\right)$ and ${K}_{P}\left(I-Q\right)N\left(\stackrel{¯}{\Omega }\right)$ are bounded. By the Arzela-Ascoli theorem, we will prove that ${K}_{P}\left(I-Q\right)N\left(\stackrel{¯}{\Omega }\right)\subset \stackrel{¯}{X}$ is equicontinuous.

From the continuity of f1, f2 and f3, there exist constants ${M}_{i}>0,\left(i=1,2,3\right)$ such that for all $\left(u,v,w\right)\in \stackrel{¯}{\Omega }$ .

$|\left(I-{Q}_{1}\right){N}_{1}v|\le {M}_{1},\text{}|\left(I-{Q}_{2}\right){N}_{2}w|\le {M}_{2},\text{}|\left(I-{Q}_{3}\right){N}_{3}u|\le {M}_{3}.$

Furthermore, for $0\le {t}_{1}<{t}_{2}\le 1,\left(u,v,w\right)\in \stackrel{¯}{\Omega }$ , we have

$\begin{array}{l}|\left({K}_{P}\left(I-Q\right)N\left(u\left({t}_{2}\right),v\left({t}_{2}\right),w\left({t}_{2}\right)\right)\right)-\left({K}_{P}\left(I-Q\right)N\left(u\left({t}_{1}\right),v\left({t}_{1}\right),w\left({t}_{1}\right)\right)\right)|\\ =|{K}_{P}\left(I-Q\right)\left({N}_{1}v\left({t}_{2}\right),{N}_{2}w\left({t}_{2}\right),{N}_{3}u\left({t}_{2}\right)\right)-{K}_{P}\left(I-Q\right)\left({N}_{1}v\left({t}_{1}\right),{N}_{2}w\left({t}_{1}\right),{N}_{3}u\left({t}_{1}\right)\right)|\\ =|\left({I}_{{0}^{+}}^{\alpha }\left(I-{Q}_{1}\right){N}_{1}v\left({t}_{2}\right),{I}_{{0}^{+}}^{\beta }\left(I-{Q}_{2}\right){N}_{2}w\left({t}_{2}\right),{I}_{{0}^{+}}^{\gamma }\left(I-{Q}_{3}\right){N}_{3}u\left({t}_{2}\right)\right)\\ \text{ }-\left({I}_{{0}^{+}}^{\alpha }\left(I-{Q}_{1}\right){N}_{1}v\left({t}_{1}\right),{I}_{{0}^{+}}^{\beta }\left(I-{Q}_{2}\right){N}_{2}w\left({t}_{1}\right),{I}_{{0}^{+}}^{\gamma }\left(I-{Q}_{3}\right){N}_{3}u\left({t}_{1}\right)\right)|\\ =|{I}_{{0}^{+}}^{\alpha }\left(I-{Q}_{1}\right){N}_{1}v\left({t}_{2}\right)-{I}_{{0}^{+}}^{\alpha }\left(I-{Q}_{1}\right){N}_{1}v\left({t}_{1}\right),\\ \text{ }{I}_{{0}^{+}}^{\beta }\left(I-{Q}_{2}\right){N}_{2}w\left({t}_{2}\right)-{I}_{{0}^{+}}^{\beta }\left(I-{Q}_{2}\right){N}_{2}w\left({t}_{1}\right),\\ \text{ }{I}_{{0}^{+}}^{\gamma }\left(I-{Q}_{3}\right){N}_{3}u\left({t}_{2}\right)-{I}_{{0}^{+}}^{\gamma }\left(I-{Q}_{3}\right){N}_{3}u\left({t}_{1}\right)|.\end{array}$

By

$\begin{array}{l}|{I}_{{0}^{+}}^{\alpha }\left(I-{Q}_{1}\right){N}_{1}v\left({t}_{2}\right)-{I}_{{0}^{+}}^{\alpha }\left(I-{Q}_{1}\right){N}_{1}v\left({t}_{1}\right)|\\ \le \frac{1}{\Gamma \left(\alpha \right)}|{\int }_{0}^{{t}_{2}}{\left({t}_{2}-s\right)}^{\alpha -1}\left(I-{Q}_{1}\right){N}_{1}v\left(s\right)\text{d}s-{\int }_{0}^{{t}_{1}}{\left({t}_{1}-s\right)}^{\alpha -1}\left(I-{Q}_{1}\right){N}_{1}v\left(s\right)\text{d}s|\\ \le \frac{{M}_{1}}{\Gamma \left(\alpha \right)}\left[{\int }_{0}^{{t}_{1}}\left({\left({t}_{2}-s\right)}^{\alpha -1}-{\left({t}_{1}-s\right)}^{\alpha -1}\right)\text{d}s+{\int }_{{t}_{1}}^{{t}_{2}}{\left({t}_{2}-s\right)}^{\alpha -1}\text{d}s\right]=\frac{{M}_{1}}{\Gamma \left(\alpha +1\right)}\left({t}_{2}^{\alpha }-{t}_{1}^{\alpha }\right)\end{array}$

and

$\begin{array}{l}|{\left({I}_{{0}^{+}}^{\alpha }\left(I-{Q}_{1}\right){N}_{1}v\right)}^{\prime }\left({t}_{2}\right)-{\left({I}_{{0}^{+}}^{\alpha }\left(I-{Q}_{1}\right){N}_{1}v\right)}^{\prime }\left({t}_{1}\right)|\\ \le \frac{\alpha -1}{\Gamma \left(\alpha \right)}|{\int }_{0}^{{t}_{2}}{\left({t}_{2}-s\right)}^{\alpha -2}\left(I-{Q}_{1}\right){N}_{1}v\left(s\right)\text{d}s-{\int }_{0}^{{t}_{1}}{\left({t}_{1}-s\right)}^{\alpha -2}\left(I-{Q}_{1}\right){N}_{1}v\left(s\right)\text{d}s|\\ \le \frac{{M}_{1}}{\Gamma \left(\alpha -1\right)}\left[{\int }_{0}^{{t}_{1}}\left({\left({t}_{2}-s\right)}^{\alpha -2}-{\left({t}_{1}-s\right)}^{\alpha -2}\right)\text{d}s+{\int }_{{t}_{1}}^{{t}_{2}}{\left({t}_{2}-s\right)}^{\alpha -2}\text{d}s\right]\\ =\frac{{M}_{1}}{\Gamma \left(\alpha \right)}\left({t}_{2}^{\alpha -1}-{t}_{1}^{\alpha -1}\right).\end{array}$

Similarly, we can show that

$|{I}_{{0}^{+}}^{\beta }\left(I-{Q}_{2}\right){N}_{2}w\left({t}_{2}\right)-{I}_{{0}^{+}}^{\beta }\left(I-{Q}_{2}\right){N}_{2}w\left({t}_{1}\right)|\le \frac{{M}_{2}}{\Gamma \left(\beta +1\right)}\left({t}_{2}^{\beta }-{t}_{1}^{\beta }\right),$

$|{\left({I}_{{0}^{+}}^{\beta }\left(I-{Q}_{2}\right){N}_{2}w\right)}^{\prime }\left({t}_{2}\right)-{\left({I}_{{0}^{+}}^{\beta }\left(I-{Q}_{2}\right){N}_{2}w\right)}^{\prime }\left({t}_{1}\right)|\le \frac{{M}_{2}}{\Gamma \left(\beta +1\right)}\left({t}_{2}^{\beta -1}-{t}_{1}^{\beta -1}\right),$

$|{I}_{{0}^{+}}^{\gamma }\left(I-{Q}_{3}\right){N}_{3}u\left({t}_{2}\right)-{I}_{{0}^{+}}^{\gamma }\left(I-{Q}_{3}\right){N}_{3}u\left({t}_{1}\right)|\le \frac{{M}_{3}}{\Gamma \left(\gamma +1\right)}\left({t}_{2}^{\gamma }-{t}_{1}^{\gamma }\right),$

$|{\left({I}_{{0}^{+}}^{\gamma }\left(I-{Q}_{3}\right){N}_{3}u\right)}^{\prime }\left({t}_{2}\right)-{\left({I}_{{0}^{+}}^{\gamma }\left(I-{Q}_{3}\right){N}_{3}u\right)}^{\prime }\left({t}_{1}\right)|\le \frac{{M}_{3}}{\Gamma \left(\gamma +1\right)}\left({t}_{2}^{\gamma -1}-{t}_{1}^{\gamma -1}\right).$

Since ${t}^{\alpha },\text{}{t}^{\alpha -1},\text{}{t}^{\beta },\text{}{t}^{\beta -1},\text{}{t}^{\gamma }$ and ${t}^{\gamma -1}$ are uniformly continuous on [0, 1], we have ${K}_{P}\left(I-Q\right)N\left(\stackrel{¯}{\Omega }\right)\subset X$ is equicontinuous. Thus ${K}_{P}\left(I-Q\right)N:\stackrel{¯}{\Omega }\to X$ is compact. $\square$

Lemma 6. Assume that $\left({H}_{1}\right),\text{}\left({H}_{2}\right)$ hold, then the set

${\Omega }_{1}=\left\{\left(u,v,w\right)\in \text{dom}L\\text{Ker}L|L\left(u,v,w\right)=\lambda N\left(u,v,w\right),\lambda \in \left(0,1\right)\right\}$

is bounded.

Proof. Let $\left(u,v,w\right)\in {\Omega }_{1}$ , then $N\left(u,v,w\right)\in \mathrm{Im}L$ . By (4), we get

${\int }_{0}^{1}{\left(1-s\right)}^{\alpha -2}{f}_{1}\left(s,v\left(s\right),{v}^{\prime }\left(s\right)\right)\text{d}s=0,$

${\int }_{0}^{1}{\left(1-s\right)}^{\beta -2}{f}_{2}\left(s,w\left(s\right),{w}^{\prime }\left(s\right)\right)\text{d}s=0$

and

${\int }_{0}^{1}{\left(1-s\right)}^{\gamma -2}{f}_{3}\left(s,u\left(s\right),{u}^{\prime }\left(s\right)\right)\text{d}s=0.$

Then, by integral mean value theorem, there exist constants $\xi ,\eta ,\zeta \in \left(0,1\right)$ such that ${f}_{1}\left(\xi ,v\left(\xi \right),{v}^{\prime }\left(\xi \right)\right)=0,{f}_{2}\left(\eta ,w\left(\left(\eta \right),{w}^{\prime }\left(\eta \right)\right)\right)=0$ and ${f}_{3}\left(\zeta ,u\left(\zeta \right),{u}^{\prime }\left(\zeta \right)\right)=0.$ Then we get

$\begin{array}{l}v\left(\xi \right){f}_{1}\left(\xi ,v\left(\xi \right),{v}^{\prime }\left(\xi \right)\right)=0,w\left(\eta \right){f}_{2}\left(\eta ,w\left(\eta \right),{w}^{\prime }\left(\eta \right)\right)=0\\ \text{and}u\left(\zeta \right){f}_{3}\left(\zeta ,u\left(\zeta \right),{u}^{\prime }\left(\zeta \right)\right)=0.\end{array}$

From $\left({\text{H}}_{\text{2}}\right)$ , we get $|v\left(\xi \right)|\le M,\text{}|w\left(\eta \right)|\le M$ and $|u\left(\zeta \right)|\le M$ . Hence we have

$|u\left(t\right)|=|u\left(\zeta \right)+{\int }_{\zeta }^{t}{u}^{\prime }\left(s\right)\text{d}s|\le M+{‖{u}^{\prime }‖}_{\infty }.$ (7)

We obtain

${‖u‖}_{\infty }\le M+{‖{u}^{\prime }‖}_{\infty }.$ (8)

Similarly, we can show that

${‖v‖}_{\infty }\le M+{‖{v}^{\prime }‖}_{\infty }$ (9)

and

${‖w‖}_{\infty }\le M+{‖{w}^{\prime }‖}_{\infty }.$ (10)

By $L\left(u,v,w\right)=\lambda N\left(u,v,w\right)$ , we get

$u\left(t\right)=\frac{\lambda }{\Gamma \left(\alpha \right)}{\int }_{0}^{t}{\left(t-s\right)}^{\alpha -1}{f}_{1}\left(s,v\left(s\right),{v}^{\prime }\left(s\right)\right)\text{d}s+u\left(0\right),$

$v\left(t\right)=\frac{\lambda }{\Gamma \left(\beta \right)}{\int }_{0}^{t}{\left(t-s\right)}^{\beta -1}{f}_{2}\left(s,w\left(s\right),{w}^{\prime }\left(s\right)\right)\text{d}s+v\left(0\right)$

and

$w\left(t\right)=\frac{\lambda }{\Gamma \left(\gamma \right)}{\int }_{0}^{t}{\left(t-s\right)}^{\gamma -1}{f}_{3}\left(s,u\left(s\right),{u}^{\prime }\left(s\right)\right)\text{d}s+w\left(0\right).$

Then

${u}^{\prime }\left(t\right)=\frac{\lambda }{\Gamma \left(\alpha -1\right)}{\int }_{0}^{t}{\left(t-s\right)}^{\alpha -2}{f}_{1}\left(s,v\left(s\right),{v}^{\prime }\left(s\right)\right)\text{d}s,$

${v}^{\prime }\left(t\right)=\frac{\lambda }{\Gamma \left(\beta -1\right)}{\int }_{0}^{t}{\left(t-s\right)}^{\beta -2}{f}_{2}\left(s,w\left(s\right),{w}^{\prime }\left(s\right)\right)\text{d}s$

and

${w}^{\prime }\left(t\right)=\frac{\lambda }{\Gamma \left(\gamma -1\right)}{\int }_{0}^{t}{\left(t-s\right)}^{\gamma -2}{f}_{3}\left(s,u\left(s\right),{u}^{\prime }\left(s\right)\right)\text{d}s.$

So,

$\begin{array}{c}{‖{u}^{\prime }‖}_{\infty }=\frac{1}{\Gamma \left(\alpha -1\right)}{\int }_{0}^{t}{\left(t-s\right)}^{\alpha -2}|{f}_{1}\left(s,v\left(s\right),{v}^{\prime }\left(s\right)\right)|\text{d}s\\ \le \frac{1}{\Gamma \left(\alpha -1\right)}{\int }_{0}^{t}{\left(t-s\right)}^{\alpha -2}\left[{a}_{1}\left(s\right)+{b}_{1}\left(s\right)|v\left(s\right)|+{c}_{1}\left(s\right)|{v}^{\prime }\left(s\right)|\right]\text{d}s\\ \le \frac{1}{\Gamma \left(\alpha -1\right)}\left[{A}_{1}+{B}_{1}M+\left({B}_{1}+{C}_{1}\right){‖{v}^{\prime }‖}_{\infty }\right]{\int }_{0}^{t}{\left(t-s\right)}^{\alpha -2}\text{d}s\\ \le \frac{1}{\Gamma \left(\alpha \right)}\left[{A}_{1}+{B}_{1}M+\left({B}_{1}+{C}_{1}\right){‖{v}^{\prime }‖}_{\infty }\right].\end{array}$ (12)

Similarly, we have

${‖{v}^{\prime }‖}_{\infty }\le \frac{1}{\Gamma \left(\beta \right)}\left[{A}_{2}+{B}_{2}M+\left({B}_{2}+{C}_{2}\right){‖{w}^{\prime }‖}_{\infty }\right]$ (12)

and

${‖{w}^{\prime }‖}_{\infty }\le \frac{1}{\Gamma \left(\gamma \right)}\left[{A}_{3}+{B}_{3}M+\left({B}_{3}+{C}_{3}\right){‖{u}^{\prime }‖}_{\infty }\right].$ (13)

Combining (13) with (12), we get

$\begin{array}{c}{‖{v}^{\prime }‖}_{\infty }\le \frac{1}{\Gamma \left(\beta \right)\Gamma \left(\gamma \right)}\left[\left({A}_{2}+{B}_{2}M\right)\Gamma \left(\gamma \right)+\left({B}_{2}+{C}_{2}\right)\left({A}_{3}+{B}_{3}M\right)\\ \text{}+\left({B}_{2}+{C}_{2}\right)\left({B}_{3}+{C}_{3}\right){‖{u}^{\prime }‖}_{\infty }\right].\end{array}$ (14)

Combining (14) with (11), we get

$\begin{array}{c}{‖{u}^{\prime }‖}_{\infty }\le \frac{1}{\Gamma \left(\alpha \right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)}\left[\left({A}_{1}+{B}_{1}M\right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)+\left({B}_{1}+{C}_{1}\right)\left({A}_{2}+{B}_{2}M\right)\Gamma \left(\gamma \right)\\ \text{}+\left({B}_{1}+{C}_{1}\right)\left({B}_{2}+{C}_{2}\right)\left({A}_{3}+{B}_{3}M\right)+\left({B}_{1}+{C}_{1}\right)\left({B}_{2}+{C}_{2}\right)\left({B}_{3}+{C}_{3}\right){‖{u}^{\prime }‖}_{\infty }\right].\end{array}$

Thus, from $\frac{\Gamma \left(\alpha \right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)-\left({B}_{1}+{C}_{1}\right)\left({B}_{2}+{C}_{2}\right)\left({B}_{3}+{C}_{3}\right)}{\Gamma \left(\alpha \right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)}>0$ and (14), we get

$\begin{array}{c}{‖{u}^{\prime }‖}_{\infty }\le \frac{1}{\Gamma \left(\alpha \right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)-\left({B}_{1}+{C}_{1}\right)\left({B}_{2}+{C}_{2}\right)\left({B}_{3}+{C}_{3}\right)}\left[\left({A}_{1}+{B}_{1}M\right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)\\ \text{}+\left({B}_{1}+{C}_{1}\right)\left({A}_{2}+{B}_{2}M\right)\Gamma \left(\gamma \right)+\left({B}_{1}+{C}_{1}\right)\left({B}_{2}+{C}_{2}\right)\left({A}_{3}+{B}_{3}M\right)\right]\\ :={K}_{1}\end{array}$

$\begin{array}{l}{‖{v}^{\prime }‖}_{\infty }\le \frac{1}{\Gamma \left(\beta \right)\Gamma \left(\gamma \right)}\left[\left({A}_{2}+{B}_{2}M\right)\Gamma \left(\gamma \right)+\left({B}_{2}+{C}_{2}\right)\left({A}_{3}+{B}_{3}M\right)\\ \text{}+\left({B}_{2}+{C}_{2}\right)\left({B}_{3}+{C}_{3}\right){K}_{1}\right]:={K}_{2}\end{array}$

and

${‖{w}^{\prime }‖}_{\infty }\le \frac{1}{\Gamma \left(\gamma \right)}\left[{A}_{3}+{B}_{3}M+\left({B}_{3}+{C}_{3}\right){K}_{1}\right]:={K}_{3}.$

From (8), (9) and (10), we have

${‖\left(u,v,w\right)‖}_{\stackrel{¯}{X}}\le \mathrm{max}\left\{{K}_{1}+M,{K}_{2}+M,{K}_{3}+M\right\}:=K.$

Hence ${\Omega }_{1}$ is bounded. $\square$

Lemma 7. Assume that $\left({H}_{3}\right)$ holds, then the set

${\Omega }_{2}=\left\{\left(u,v,w\right)|\left(u,v,w\right)\in \text{Ker}L,N\left(u,v,w\right)\in \mathrm{Im}L\right\}$

is bounded.

Proof. For $\left(u,v,w\right)\in {\Omega }_{2}$ , we have $\left(u,v,w\right)=\left({m}_{1},{m}_{2},{m}_{3}\right),\text{}{m}_{1},{m}_{2},{m}_{3}\in R$ . Then from $N\left(u,v,w\right)\in \mathrm{Im}L$ ,

${\int }_{0}^{1}{\left(1-s\right)}^{\alpha -2}{f}_{1}\left(s,{m}_{2},0\right)\text{d}s=0,$

${\int }_{0}^{1}{\left(1-s\right)}^{\beta -2}{f}_{2}\left(s,{m}_{3},0\right)\text{d}s=0$

and

${\int }_{0}^{1}{\left(1-s\right)}^{\gamma -2}{f}_{3}\left(s,{m}_{1},0\right)\text{d}s=0.$

From $\left({\text{H}}_{3}\right)$ imply that $|{m}_{1}|,\text{}|{m}_{2}|,\text{}|{m}_{3}|\le {M}^{*}$ . Thus, we get

${‖\left(u,v,w\right)‖}_{\stackrel{¯}{X}}\le {M}^{*}.$

Therefore ${\Omega }_{2}$ is bounded. $\square$

Lemma 8. Assume that the first part of $\left({H}_{3}\right)$ holds, then the set

${\Omega }_{3}=\left\{\left(u,v,w\right)\in \text{Ker}L|\lambda \left(u,v,w\right)+\left(1-\lambda \right)QN\left(u,v,w\right)=\left(0,0,0\right),\lambda \in \left[0,1\right]\right\}$

is bounded.

Proof. For $\left(u,v,w\right)\in {\Omega }_{3}$ , we have $\left(u,v,w\right)=\left({m}_{1},{m}_{2},{m}_{3}\right),\text{}{m}_{1},{m}_{2},{m}_{3}\in R$ and

$\lambda {m}_{1}+\left(1-\lambda \right)\left(\alpha -1\right){\int }_{0}^{1}{\left(1-s\right)}^{\alpha -2}{f}_{1}\left(s,{m}_{2},0\right)\text{d}s=0,$ (15)

$\lambda {m}_{2}+\left(1-\lambda \right)\left(\beta -1\right){\int }_{0}^{1}{\left(1-s\right)}^{\beta -2}{f}_{2}\left(s,{m}_{3},0\right)\text{d}s=0$ (16)

and

$\lambda {m}_{3}+\left(1-\lambda \right)\left(\gamma -1\right){\int }_{0}^{1}{\left(1-s\right)}^{\gamma -2}{f}_{3}\left(s,{m}_{1},0\right)\text{d}s=0.$ (17)

If $\lambda =0$ , then by $\left({H}_{3}\right)$ , we get $|{m}_{1}|,\text{}|{m}_{2}|,\text{}|{m}_{3}|\le {M}^{*}$ . If $\lambda =1$ , then ${m}_{1}={m}_{2}={m}_{3}=0$ . For $\lambda \in \left(0,1\right]$ , we obtain $|{m}_{1}|,\text{}|{m}_{2}|,\text{}|{m}_{3}|\le {M}^{*}$ . Otherwise, if $|{m}_{1}|$ or $|{m}_{2}|$ or $|{m}_{3}|>{M}^{*}$ , from $\left({H}_{3}\right)$ , one has

$\lambda {m}_{1}^{2}+\left(1-\lambda \right)\left(\alpha -1\right){\int }_{0}^{1}{\left(1-s\right)}^{\alpha -2}{m}_{1}{f}_{1}\left(s,{m}_{2},0\right)\text{d}s>0$

or

$\lambda {m}_{2}^{2}+\left(1-\lambda \right)\left(\beta -1\right){\int }_{0}^{1}{\left(1-s\right)}^{\beta -2}{m}_{2}{f}_{2}\left(s,{m}_{3},0\right)\text{d}s>0$

or

$\lambda {m}_{3}^{2}+\left(1-\lambda \right)\left(\gamma -1\right){\int }_{0}^{1}{\left(1-s\right)}^{\gamma -2}{m}_{3}{f}_{3}\left(s,{m}_{1},0\right)\text{d}s>0,$

which contradict to (15) or (16) or (17). Hence, ${\Omega }_{3}$ is bounded.

Remark 1 Suppose the second part of $\left({H}_{3}\right)$ holds, then the set

${{\Omega }^{\prime }}_{3}=\left\{\left(u,v,w\right)\in \text{Ker}L|-\lambda \left(u,v,w\right)+\left(1-\lambda \right)QN\left(u,v,w\right)=\left(0,0,0\right),\lambda \in \left[0,1\right]\right\}$

is bounded. $\square$

Proof of the Theorem 1: Set $\Omega =\left\{\left(u,v,w\right)\in \stackrel{¯}{X}|{‖\left(u,v,w\right)‖}_{\stackrel{¯}{X}}<\mathrm{max}\left\{K,{M}^{*}\right\}+1\right\}$ .

From the Lemma 4 and Lemma 5 we can get L is a Fredholm operator of index zero and N is L-compact on $\stackrel{¯}{\Omega }$ . By Lemma 6 and Lemma 7, we obtain

(1) $L\left(u,v,w\right)\ne \lambda N\left(u,v,w\right)$ for every $\left(\left(u,v,w\right),\lambda \right)\in \left[\left(\text{dom}L\\text{Ker}L\right)\cap \partial \Omega \right]×\left(0,1\right)$ ;

(2) $Nx\notin \mathrm{Im}L$ for every $\left(u,v,w\right)\in \text{Ker}L\cap \partial \Omega$ .

Choose

$H\left(\left(u,v,w\right),\lambda \right)=±\lambda \left(u,v,w\right)+\left(1-\lambda \right)QN\left(u,v,w\right).$

By Lemma 8 (or Remark 1), we get $H\left(\left(u,v,w\right),\lambda \right)\ne 0$ for $\left(u,v,w\right)\in \text{Ker}L\cap \partial \Omega$ . Therefore

$\begin{array}{c}\mathrm{deg}\left({QN|}_{\text{Ker}L},\text{Ker}L\cap \Omega ,0\right)=\mathrm{deg}\left(H\left(.,0\right),\text{Ker}L\cap \Omega ,0\right)\\ =\mathrm{deg}\left(H\left(.,1\right),\text{Ker}L\cap \Omega ,0\right)\\ =\mathrm{deg}\left(±I,\text{Ker}L\cap \Omega ,0\right)\ne 0.\end{array}$

Thus, the condition (3) of Lemma 1 is satisfied. By Lemma 1, we obtain $L\left(u,v,w\right)=N\left(u,v,w\right)$ has at least one solution in $\text{dom}L\cap \stackrel{¯}{\Omega }$ . Hence Neumann boundary value problem (1) has at least one solution. This completes the proof.

4. Examples

In this section, we give two examples to illustrate our main results.

Example 1. Consider the following Neumann boundary value problem of fractional differential equation of the form

$\begin{array}{l}{D}_{{0}^{+}}^{\frac{5}{4}}u\left(t\right)=\frac{1}{8}\left(v\left(t\right)-6\right)+\frac{{t}^{2}}{8}{\left(1+{v}^{\prime }\left(t\right)\right)}^{\frac{1}{2}},\text{}t\in \left(0,1\right),\\ {D}_{{0}^{+}}^{\frac{3}{2}}v\left(t\right)=\frac{1}{6}\left(w\left(t\right)-4\right)+\frac{{t}^{3}}{6}{\mathrm{cos}}^{2}{w}^{\prime }\left(t\right),\text{}t\in \left(0,1\right),\\ {D}_{{0}^{+}}^{\frac{7}{4}}w\left(t\right)=\frac{1}{10}\left(u\left(t\right)-8\right)+\frac{{t}^{3}}{10}{\mathrm{sin}}^{2}{u}^{\prime }\left(t\right),\text{}t\in \left(0,1\right),\\ {u}^{\prime }\left(0\right)={u}^{\prime }\left(1\right)=0,\text{}{v}^{\prime }\left(0\right)={v}^{\prime }\left(1\right)=0,\text{}{w}^{\prime }\left(0\right)={w}^{\prime }\left(1\right)=0.\end{array}$ (18)

Here $\alpha =\frac{5}{4},\text{}\beta =\frac{3}{2},\text{}\gamma =\frac{7}{4}$ . Moreover,

${f}_{1}\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right)=\frac{1}{8}\left(v\left(t\right)-6\right)+\frac{{t}^{2}}{8}{\left(1+{v}^{\prime }\left(t\right)\right)}^{\frac{1}{2}},$

${f}_{2}\left(t,w\left(t\right),{w}^{\prime }\left(t\right)\right)=\frac{1}{6}\left(w\left(t\right)-4\right)+\frac{{t}^{3}}{6}{\mathrm{cos}}^{2}{w}^{\prime }\left(t\right),$

${f}_{3}\left(t,u\left(t\right),{u}^{\prime }\left(t\right)\right)=\frac{1}{10}\left(u\left(t\right)-8\right)+\frac{{t}^{3}}{10}{\mathrm{sin}}^{2}{u}^{\prime }\left(t\right).$

Now let us compute ${a}_{1}\left(t\right),\text{}{b}_{1}\left(t\right),\text{}{c}_{1}\left(t\right)$ from ${f}_{1}\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right)$ .

$\begin{array}{c}{f}_{1}\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right)=\frac{1}{8}\left(v\left(t\right)-6\right)+\frac{{t}^{2}}{8}{\left(1+{v}^{\prime }\left(t\right)\right)}^{\frac{1}{2}}\\ =\frac{1}{8}\left(v\left(t\right)-6\right)+\frac{{t}^{2}}{8}\left(1+\frac{1}{2}{v}^{\prime }\left(t\right)+\cdots \right)\\ \le \frac{1}{8}\left(v\left(t\right)-6\right)+\frac{{t}^{2}}{8}.\end{array}$

$|{f}_{1}\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right)|\le \frac{1}{8}|v\left(t\right)|+\frac{7}{8}.$

From the above inequality, we get ${a}_{1}\left(t\right)=\frac{7}{8},\text{}{b}_{1}\left(t\right)=\frac{1}{8},\text{}{c}_{1}\left(t\right)=0.$ Also,

${f}_{2}\left(t,w\left(t\right),{w}^{\prime }\left(t\right)\right)=\frac{1}{6}\left(w\left(t\right)-4\right)+\frac{{t}^{3}}{6}{\mathrm{cos}}^{2}{w}^{\prime }\left(t\right)$

$|{f}_{2}\left(t,w\left(t\right),{w}^{\prime }\left(t\right)\right)|\le \frac{1}{6}|w\left(t\right)|+\frac{5}{6}.$

Here, ${a}_{2}\left(t\right)=\frac{5}{6},\text{}{b}_{2}\left(t\right)=\frac{1}{6},\text{}{c}_{2}\left(t\right)=0$ . Finally,

${f}_{3}\left(t,u\left(t\right),{u}^{\prime }\left(t\right)\right)=\frac{1}{10}\left(u\left(t\right)-8\right)+\frac{{t}^{3}}{10}{\mathrm{sin}}^{2}{u}^{\prime }\left(t\right).$

$|{f}_{3}\left(t,u\left(t\right),{u}^{\prime }\left(t\right)\right)|\le \frac{1}{10}|u\left(t\right)|+\frac{8}{10}.$

We get, ${a}_{3}\left(t\right)=\frac{4}{5},\text{}{b}_{3}\left(t\right)=\frac{1}{10},\text{}{c}_{3}\left(t\right)=0$ . And we get, ${B}_{1}\left(t\right)=\frac{1}{8},$ ${B}_{2}\left(t\right)=\frac{1}{6},$ ${B}_{3}\left(t\right)=\frac{1}{10},$ ${C}_{1}\left(t\right)={C}_{2}\left(t\right)={C}_{3}\left(t\right)=0$ . Choose $M={M}^{*}=8$ . Also,

$\begin{array}{c}\frac{\Gamma \left(\alpha \right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)-\left({B}_{1}+{C}_{1}\right)\left({B}_{2}+{C}_{2}\right)\left({B}_{3}+{C}_{3}\right)}{\Gamma \left(\alpha \right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)}\\ =\frac{\Gamma \left(\frac{5}{4}\right)\Gamma \left(\frac{3}{2}\right)\Gamma \left(\frac{7}{4}\right)-\left({B}_{1}{B}_{2}{B}_{3}\right)}{\Gamma \left(\frac{5}{4}\right)\Gamma \left(\frac{3}{2}\right)\Gamma \left(\frac{7}{4}\right)}\\ \approx 0.73605543>0,\end{array}$

where $\Gamma \left(\frac{1}{4}\right)\approx 3.625,\text{}\Gamma \left(\frac{3}{4}\right)\approx 1.225416702$ and $\Gamma \left(\frac{1}{2}\right)=\sqrt{\text{π}}$ . All the condi-

tions of Theorem 1 are satisfied. Hence, boundary value problem (18) has at least one solution.

Example 2. Consider the Neumann boundary value problem of fractional differential equation of the following form

$\begin{array}{l}{D}_{{0}^{+}}^{\frac{4}{3}}u\left(t\right)=\frac{1}{17}\left(v\left(t\right)-15\right)+\frac{{t}^{4}}{20}\mathrm{log}\left(1+{v}^{\prime }\left(t\right)\right),t\in \left(0,1\right),\\ {D}_{{0}^{+}}^{\frac{5}{4}}v\left(t\right)=\frac{1}{9}\left(w\left(t\right)-7\right)+\frac{{t}^{6}}{25}{\left(1+{w}^{\prime }\left(t\right)\right)}^{\frac{1}{3}},t\in \left(0,1\right),\\ {D}_{{0}^{+}}^{\frac{3}{2}}w\left(t\right)=\frac{1}{13}\left(u\left(t\right)-11\right)+\frac{{t}^{7}}{15}\mathrm{arctan}{u}^{\prime }\left(t\right),t\in \left(0,1\right),\\ {u}^{\prime }\left(0\right)={u}^{\prime }\left(1\right)=0,\text{}{v}^{\prime }\left(0\right)={v}^{\prime }\left(1\right)=0,\text{}{w}^{\prime }\left(0\right)={w}^{\prime }\left(1\right)=0.\end{array}$ (19)

Here $\alpha =\frac{4}{3},\text{}\beta =\frac{5}{4},\text{}\gamma =\frac{3}{2}$ . Moreover,

${f}_{1}\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right)=\frac{1}{17}\left(v\left(t\right)-15\right)+\frac{{t}^{4}}{20}\mathrm{log}\left(1+{v}^{\prime }\left(t\right)\right),$

${f}_{2}\left(t,w\left(t\right),{w}^{\prime }\left(t\right)\right)=\frac{1}{9}\left(w\left(t\right)-7\right)+\frac{{t}^{6}}{25}{\left(1+{w}^{\prime }\left(t\right)\right)}^{\frac{1}{3}},$

${f}_{3}\left(t,u\left(t\right),{u}^{\prime }\left(t\right)\right)=\frac{1}{13}\left(u\left(t\right)-11\right)+\frac{{t}^{7}}{15}\mathrm{arctan}{u}^{\prime }\left(t\right).$

Now let us compute ${a}_{1}\left(t\right),\text{}{b}_{1}\left(t\right),\text{}{c}_{1}\left(t\right)$ from ${f}_{1}\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right)$ .

$\begin{array}{c}{f}_{1}\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right)=\frac{1}{17}\left(v\left(t\right)-15\right)+\frac{{t}^{4}}{20}\mathrm{log}\left(1+{v}^{\prime }\left(t\right)\right)\\ =\frac{1}{17}\left(v\left(t\right)-15\right)+\frac{{t}^{4}}{20}\left({v}^{\prime }\left(t\right)-\frac{{\left({v}^{\prime }\left(t\right)\right)}^{2}}{2!}+\cdots \right)\end{array}$

$|{f}_{1}\left(t,v\left(t\right),{v}^{\prime }\left(t\right)\right)|\le \frac{1}{17}|v\left(t\right)|+\frac{15}{17}+\frac{1}{20}|{v}^{\prime }\left(t\right)|$

From the above inequality, we get ${a}_{1}\left(t\right)=\frac{15}{17},{b}_{1}\left(t\right)=\frac{1}{17},{c}_{1}\left(t\right)=\frac{1}{20}.$ Also,

$\begin{array}{c}{f}_{2}\left(t,w\left(t\right),{w}^{\prime }\left(t\right)\right)=\frac{1}{9}\left(w\left(t\right)-7\right)+\frac{{t}^{6}}{25}{\left(1+{w}^{\prime }\left(t\right)\right)}^{\frac{1}{3}}\\ =\frac{1}{9}\left(w\left(t\right)-7\right)+\frac{{t}^{6}}{25}\left(1+\frac{1}{3}{w}^{\prime }\left(t\right)+\cdots \right)\end{array}$

$\begin{array}{c}|{f}_{2}\left(t,w\left(t\right),{w}^{\prime }\left(t\right)\right)|\le \frac{1}{9}|w\left(t\right)|+\frac{7}{9}+\frac{1}{25}\left(1+\frac{1}{3}|{w}^{\prime }\left(t\right)|+\cdots \right)\\ \le \frac{1}{9}|w\left(t\right)|+\frac{184}{225}+\frac{1}{75}|{w}^{\prime }\left(t\right)|.\end{array}$

Here, ${a}_{2}\left(t\right)=\frac{184}{225},{b}_{2}\left(t\right)=\frac{1}{9},{c}_{2}\left(t\right)=\frac{1}{75}$ . Similarly,

$\begin{array}{c}{f}_{3}\left(t,u\left(t\right),{u}^{\prime }\left(t\right)\right)=\frac{1}{13}\left(u\left(t\right)-11\right)+\frac{{t}^{7}}{10}\mathrm{arctan}{u}^{\prime }\left(t\right).\\ =\frac{1}{13}\left(u\left(t\right)-11\right)+\frac{{t}^{7}}{15}\left({u}^{\prime }\left(t\right)-\frac{\left({u}^{\prime }{\left(t\right)}^{3}\right)}{3}+\cdots \right).\end{array}$

$|{f}_{3}\left(t,u\left(t\right),{u}^{\prime }\left(t\right)\right)|\le \frac{1}{13}|u\left(t\right)|+\frac{11}{13}+\frac{1}{15}{u}^{\prime }\left(t\right).$

Here, ${a}_{3}\left(t\right)=\frac{11}{13},\text{}{b}_{3}\left(t\right)=\frac{1}{13},\text{}{c}_{3}\left(t\right)=\frac{1}{15}$ . We get, ${B}_{1}\left(t\right)=\frac{1}{17},$ ${B}_{2}\left(t\right)=\frac{1}{9},$ ${B}_{3}\left(t\right)=\frac{1}{13},$ ${C}_{1}\left(t\right)=\frac{1}{20},$ ${C}_{2}\left(t\right)=\frac{1}{75},$ ${C}_{3}\left(t\right)=\frac{1}{15}$ . Choose $M={M}^{*}=15$ .

Also,

$\begin{array}{c}\frac{\Gamma \left(\alpha \right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)-\left({B}_{1}+{C}_{1}\right)\left({B}_{2}+{C}_{2}\right)\left({B}_{3}+{C}_{3}\right)}{\Gamma \left(\alpha \right)\Gamma \left(\beta \right)\Gamma \left(\gamma \right)}\\ =\frac{\Gamma \left(\frac{4}{3}\right)\Gamma \left(\frac{5}{4}\right)\Gamma \left(\frac{3}{2}\right)-\left(\left(\frac{1}{17}+\frac{1}{20}\right)\left(\frac{1}{9}+\frac{1}{75}\right)\left(\frac{1}{13}+\frac{1}{15}\right)\right)}{\Gamma \left(\frac{4}{3}\right)\Gamma \left(\frac{5}{4}\right)\Gamma \left(\frac{3}{2}\right)}\\ \approx 0.96872>0,\end{array}$

where $\Gamma \left(\frac{1}{4}\right)\approx 3.625,\text{}\Gamma \left(\frac{1}{3}\right)\approx 0.1924$ and $\Gamma \left(\frac{1}{2}\right)=\sqrt{\text{π}}$ . Hence all the condi-

tions of Theorem 1 are satisfied. Therefore, boundary value problem (19) has at least one solution.

5. Conclusion

We have investigated some existence results for three-dimensional fractional differential system with Neumann boundary condition. By using Mawhin’s coin- cidence degree theory, we established that the given boundary value problem admits at least one solution. We also presented examples to illustrate the main results.

Acknowledgements

The authors would like to thank the anonymous reviewers for their valuable comments and suggestions to improve the quality of the manuscript.

Conflicts of Interest

The authors declare no conflicts of interest.

Cite this paper

Sadhasivam, V. , Kavitha, J. and Deepa, M. (2017) Existence of Solutions of Three-Dimensional Fractional Differential Systems. Applied Mathematics, 8, 193-208. doi: 10.4236/am.2017.82016.

  Miller, K.S. and Ross, B. (1993) An Introduction to the Fractional Calculus and Fractional Differential Equations. Wiley, New York.  Samko, S.G., Kilbas, A.A. and Marichev, O.I. (1993) Fractional Integrals and Derivatives. Gordon and Breach Science Publishers, Yverdon.  Hilfer, Z. (2000) Appliations of Fractional Calculus in Physics. World Scientific, Singapore. https://doi.org/10.1142/3779  Metzler, R. and Klafter, J. (2000) Boundary Value Problems for Fractional Diffusion Equations. Physics A, 278, 107-125. https://doi.org/10.1016/S0378-4371(99)00503-8  Kilbas, A.A., Srivastava, H.M. and Trujillo, J.J. (2006) Theory and Applications of Fractional Differential Equations. Elsevier, Amsterdam.  Lakshmikantham, V., Leela, S. and Vasundhara Devi, J. (2009) Theory of Fractional Dynamic Systems. Cambridge Academic Publishers, Cambridge.  Mainardi, A. (2010) Fractional Calculus and Waves in Linear Viscoelasticity. Imperial College Press, London. https://doi.org/10.1142/p614  Abbas, S., Benchora, M. and N’Guerekata, G.M. (2012) Topics in Fractional Differential Equations. Springer, New York. https://doi.org/10.1007/978-1-4614-4036-9  Zhou, Y. (2014) Basic Theory of Fractional Differential Equations. World Scientific, Singapore. https://doi.org/10.1142/9069  Ahmad, B. and Nieto, J.J. (2009) Existence Results for a Coupled System of Nonlinear Fractional Differential Equations with Three-Point Boundary Conditions. Computers and Mathematics with Applications, 58, 1838-1843. https://doi.org/10.1016/j.camwa.2009.07.091  Liu, Y., Ahmad, B. and Agarwal, R.P. (2013) Existence of Solutions for a Coupled System of Nonlinear Fractional Differential Equations with Fractional Boundary Conditions on the Half-Line. Advances in Difference Equations, 2013, 46. https://doi.org/10.1186/1687-1847-2013-46  Aphithana, A., Ntouyas, S.K. and Tariboon, J. (2015) Existence and Uniqueness of Symmetric Solutions for Fractional Differential Equations with Multi-Point Fractional Integral Conditions. Boundary Value Problems, 2015, 68. https://doi.org/10.1186/s13661-015-0329-1  Wang, Y. (2016) Positive Solutions for Fractional Differential Equation Involving the Riemann-Stieltjes Integral Conditions with Two Parameters. Journal of Nonlinear Science and Applications, 9, 5733-5740.  Mawhin, J. (1993) Topological Degree and Boundary Value Problems for Nonlinear Differential Equations in Topological Methods for Ordinary Differential Equations. Lecture Notes in Mathematics, 1537, 74-142. https://doi.org/10.1007/BFb0085076  Kosmatov, N. (2010) A Boundary Value Problem of Fractional Order at Resonance. Electronic Journal of Differential Equations, 135, 1-10.  Bai, Z. and Zhang, Y. (2010) The Existence of Solutions for a Fractional Multi-Point Boundary Value Problem. Computers and Mathematics with Applications, 60, 2364-2372. https://doi.org/10.1016/j.camwa.2010.08.030  Wang, G., Liu, W., Zhu, S. and Zheng, T. (2011) Existence Results for a Coupled System of Nonlinear Fractional 2m-Point Boundary Value Problems at Resonance. Advances in Difference Equations, 44, 1-17. https://doi.org/10.1155/2011/783726  Zhang, Y., Bai, Z. and Feng, T. (2011) Existence Results for a Coupled System of Nonlinear Fractional Three-Point Boundary Value Problems at Resonance. Computers and Mathematics with Applications, 61, 1032-1047. https://doi.org/10.1016/j.camwa.2010.12.053  Jiang, W. (2012) Solvability for a Coupled System of Fractional Differential Equations at Resonance. Nonlinear Analysis, 13, 2285-2292. https://doi.org/10.1016/j.nonrwa.2012.01.023  Hu, Z., Liu, W. and Rui, W. (2012) Existence of Solutions for a Coupled System of Fractional Differential Equations. Springer, Berlin, 1-15. https://doi.org/10.1186/1687-2770-2012-98  Hu, L. (2016) On the Existence of Positive Solutions for Fractional Differential Inclusions at Resonance. SpringerPlus, 5, 957. https://doi.org/10.1186/s40064-016-2665-8  Hu, Z., Liu, W. and Chen, T. (2011) Two-Point Boundary Value Problems for Fractional Differential Equations at Resonance. Bulletin of the Malaysian Mathematical Society Series, 3, 747-755.  Hu, Z., Liu, W. and Chen, T. (2012) Existence of Solutions for a Coupled System of Fractional Differential Equations at Resonance. Boundary Value Problems, 2012, 98. https://doi.org/10.1186/1687-2770-2012-98

comments powered by Disqus

Copyright © 2018 by authors and Scientific Research Publishing Inc. This work and the related PDF file are licensed under a Creative Commons Attribution 4.0 International License.
