Investigation of a Counter Flow Microchannel Heat Exchanger Performance with Using Nanofluid as a Coolant

Full-Text HTML Download Download as PDF (Size:515KB) PP. 35-43
DOI: 10.4236/jectc.2012.23004    5,454 Downloads   13,722 Views   Citations


In this paper the performance of a counter flow microchannel heat exchanger (CFMCHE) is numerically investigated with a nanofluid as a cooling medium. Two types of nanofluids are used Cu-water and Al2O3-water. From the results obtained it’s found that thermal performance of CFMCHE increased with using the nanofluids as cooling medium with no extra increase in pressure drop due to the ultra fine solid particles and low volume fraction concentrations. The na-nofluids (Cu-water and Al2O3-water) volume fractions were in the range 1% to 5%. It’s also found that nanoflu-id-cooled CFMCHE could absorb more heat than water-cooled CFMCHE when the flow rate was low. For high flow rates the heat transfer was dominated by the volume flow rate and nanoparticles did not contribute to the extra heat absorption. Also the performance of CFMCHE can be increased considerably by using nanofluids with higher thermal conductivities.

Cite this paper

Hasan, M. , Rageb, A. and Yaghoubi, M. (2012) Investigation of a Counter Flow Microchannel Heat Exchanger Performance with Using Nanofluid as a Coolant. Journal of Electronics Cooling and Thermal Control, 2, 35-43. doi: 10.4236/jectc.2012.23004.


[1] D. B. Tuckerman and R. F. W. Pease, “High-Performance Heat Sinking for VLSI,” IEEE Electron Device Letters, Vol. 2, No. 5, 1981, pp. 126-129. doi:10.1109/EDL.1981.25367
[2] X. W. Wang, X. F. Xu and S. U. S. Choi, “Thermal Conductivity of Nanoparticle-Fluid Mixture,” Journal of Thermophysics and Heat Transfer, Vol. 13, No. 4, 1999, pp. 474-480.
[3] S. Lee, S. U. S. Choi, S. Li and J. A. Estman, “Measuring Thermal Conductivity of Fluids Containing Oxide Nanoparticles,” Journal of Heat Transfer, Vol. 121, No. 2, 1999, pp. 280-289. doi:10.1115/1.2825978
[4] B.-X.Wang, L.-P.Zhou and X.-F. Peng, “A Fractal Model for Predicting the Effective Thermal Conductivity of Liquid with Suspension of Nanoparticles,” International Journal of Heat and Mass Transfer, Vol. 46, No. 14, 2003, pp. 2665-2672. doi:10.1016/S0017-9310(03)00016-4
[5] J. Koo and C. Kleinstreuer, “A New Thermal Conductivity Model for Nanofluids,” Journal of Nanoparticle Research, Vol. 6, No. 6, 2004, pp. 577-588. doi:10.1007/s11051-004-3170-5
[6] Q. Li and Y. M. Xuan, “Convective Heat Transfer and Flow Characteristics of Cu-Water Nanofluid,” Science in China Series E: Technological Sciences, Vol. 45, No. 4, 2002, pp. 408-416.
[7] Y. M. Xuan and Q. Li, “Investigation on Convective Heat Transfer and Flow Features of Nanofluids,” Journal of Heat Transfer, Vol. 125, No. 1, 2003, pp. 151-155. doi:10.1115/1.1532008
[8] B. C. Pak and Y. I. Cho, “Hydrodynamic and Heat Transfer Study of Dispersed Fluids with Submicron Metallic Oxide Particles,” Experimental Heat Transfer, Vol. 11, No. 2, 1998, pp. 151170. doi:10.1080/08916159808946559
[9] D. S. Wen and Y. L. Ding, “Experimental Investigation into Convective Heat Transfer of Nanofluids at the Entrance Region under Laminar Flow Conditions,” International Journal of Heat and Mass Transfer, Vol. 47, No. 24, 2004, pp. 5181-5188. doi:10.1016/j.ijheatmasstransfer.2004.07.012
[10] S. P. Jang and S. U. S. Choi, “Cooling Performance of a Microchannel Heat Sink with Nanofluids,” Applied Thermal Engineering, Vol. 26, No. 17-18, 2006, pp. 2457-2463. doi:10.1016/j.applthermaleng.2006.02.036
[11] T.-H. Tsai and R. Chein, “Performance Analysis of Nanofluid-Cooled Microchannel Heat Sinks,” International Journal of Heat and Fluid Flow, Vol. 28, No. 5, 2007, pp. 1013-1026. doi:10.1016/j.ijheatfluidflow.2007.01.007
[12] J. Lee and I. Mudawar, “Assessment of the Effectiveness of Nanofluids for Single-Phase and Two-Phase Heat Transfer in Micro-Channels,” International Journal of Heat and Mass Transfer, Vol. 50, No. 3-4, 2007, pp. 452463. doi:10.1016/j.ijheatmasstransfer.2006.08.001
[13] M. I. Hasan, A. A. Rageb, M. Yaghoubi and H. Homayony, “Influence of Channel Geometry on the Performance of Counter Flow Microchannel Heat Exchanger,” International Journal of Thermal Sciences, Vol. 48, No. 8, 2009, pp. 1607-1618. doi:10.1016/j.ijthermalsci.2009.01.004
[14] M. I. Hasan, “Numerical Investigation of Counter Flow Microchannel Heat Exchanger with MEPCM Suspension,” Applied Thermal Engineering, Vol. 31, No. 6-7, 2011, pp. 1068-1075. doi:10.1016/j.applthermaleng.2010.11.032
[15] R. Chein and J. Chuang, “Experimental Microchannel Heat Sink Performance Studies Using Nanofluids,” International Journal of Thermal Sciences, Vol. 46, No. 1, 2007, pp. 57-66. doi:10.1016/j.ijthermalsci.2006.03.009
[16] S. V. Patankar, “Numerical Heat Transfer and Fluid Flow,” Hemisphere Publishing Corporation, Washington DC, New York, London, 1980.
[17] F. P. Incropera and D. P. Dewitt, “Fundamentals of heat and mass transfer,” 4th Edition, John Wiley and Sons, Hoboken, 1996.
[18] Weilin Q., Issam M., “Thermal Design Methodology for High-Heat-Flux Single Phase and Two Phase Microchannel Heat Sinks,” IEEE Transactions on Components and Packaging Technologies, Vol. 26, No. 3, 2003, pp. 598-609. doi:10.1109/TCAPT.2003.817652
